Espressif Systems ESP8266 Beginner's Manual page 33

Uploading files to the server
There are scenarios where you may want to upload new files to the server from within a browser, without having to connect to the
ESP8266 over USB in order to flash a new SPIFFS image.
In this chapter, I'll show you how to use HTML forms and POST requests to upload or edit files to our little ESP server.
Client: HTML form
The easiest way to upload files is by using an HTML form, just like in the first server examples, where we used forms to turn on/off
LEDs, and to send the login credentials back to the server. If you choose a file input, you automatically get a file picker, and the
browser will send the right POST request to the server, with the file attached.
<form method="post" enctype="multipart/form-data">
<input type="file" name="name">
<input class="button" type="submit" value="Upload">
</form>
Server
In the ESP code, we have to add a handler to our server that handles POST requests to the /upload URI. When it receives a POST
request, it sends a status 200 (OK) back to the client to start receiving the file, and then write it to the SPIFFS. When the file is
uploaded successfully, it redirects the client to a success page.
The relevant new code is found in the
#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WiFiMulti.h>
#include <ESP8266mDNS.h>
#include <ESP8266WebServer.h>
#include <FS.h> // Include the SPIFFS library
ESP8266WiFiMulti wifiMulti; // Create an instance of the ESP8266WiFiMulti class, called 'wifiMulti'
ESP8266WebServer server(80); // Create a webserver object that listens for HTTP request on port 80
File fsUploadFile; // a File object to temporarily store the received file
String getContentType(String filename); // convert the file extension to the MIME type
bool handleFileRead(String path); // send the right file to the client (if it exists)
void handleFileUpload(); // upload a new file to the SPIFFS
void setup() {
Serial.begin(115200); // Start the Serial communication to send messages to the computer
delay(10);
Serial.println('\n');
wifiMulti.addAP("ssid_from_AP_1", "your_password_for_AP_1"); // add Wi-Fi networks you want to connect to
wifiMulti.addAP("ssid_from_AP_2", "your_password_for_AP_2");
wifiMulti.addAP("ssid_from_AP_3", "your_password_for_AP_3");
Serial.println("Connecting ...");
int i = 0;
while (wifiMulti.run() != WL_CONNECTED) { // Wait for the Wi-Fi to connect
delay(1000);
Serial.print(++i); Serial.print(' ');
}
Serial.println('\n');
Serial.print("Connected to ");
Serial.println(WiFi.SSID()); // Tell us what network we're connected to
Serial.print("IP address:\t");
Serial.println(WiFi.localIP()); // Send the IP address of the ESP8266 to the computer
if (!MDNS.begin("esp8266")) { // Start the mDNS responder for esp8266.local
Serial.println("Error setting up MDNS responder!");
}
Serial.println("mDNS responder started");
SPIFFS.begin(); // Start the SPI Flash Files System
server.on("/upload", HTTP_GET, []() { // if the client requests the upload page
if (!handleFileRead("/upload.html")) // send it if it exists
server.send(404, "text/plain", "404: Not Found"); // otherwise, respond with a 404 (Not Found) error
});
server.on("/upload", HTTP_POST, // if the client posts to the upload page
[](){ server.send(200); }, // Send status 200 (OK) to tell the client we are ready to receive
handleFileUpload // Receive and save the file
);
server.onNotFound([]() { // If the client requests any URI
if (!handleFileRead(server.uri())) // send it if it exists
server.send(404, "text/plain", "404: Not Found"); // otherwise, respond with a 404 (Not Found) error
});
server.begin(); // Actually start the server
Serial.println("HTTP server started");
}
void loop() {
server.handleClient();
}
String getContentType(String filename) { // convert the file extension to the MIME type
if (filename.endsWith(".html")) return "text/html";
else if (filename.endsWith(".css")) return "text/css";
else if (filename.endsWith(".js")) return "application/javascript";
else if (filename.endsWith(".ico")) return "image/x-icon";
else if (filename.endsWith(".gz")) return "application/x-gzip";
return "text/plain";
}
and the
setup handleFileUpload
function.
