Espressif Systems ESP8266 Beginner's Manual page 39

while (dir.next()) { // List the file system contents
String fileName = dir.fileName();
size_t fileSize = dir.fileSize();
Serial.printf("\tFS File: %s, size: %s\r\n", fileName.c_str(), formatBytes(fileSize).c_str());
}
Serial.printf("\n");
}
}
void startWebSocket() { // Start a WebSocket server
webSocket.begin(); // start the websocket server
webSocket.onEvent(webSocketEvent); // if there's an incomming websocket message, go to function 'webSocketEvent'
Serial.println("WebSocket server started.");
}
void startMDNS() { // Start the mDNS responder
MDNS.begin(mdnsName); // start the multicast domain name server
Serial.print("mDNS responder started: http://");
Serial.print(mdnsName);
Serial.println(".local");
}
void startServer() { // Start a HTTP server with a file read handler and an upload handler
server.on("/edit.html", HTTP_POST, []() { // If a POST request is sent to the /edit.html address,
server.send(200, "text/plain", "");
}, handleFileUpload); // go to 'handleFileUpload'
server.onNotFound(handleNotFound); // if someone requests any other file or page, go to function 'handleNotFound'
// and check if the file exists
server.begin(); // start the HTTP server
Serial.println("HTTP server started.");
}
These are the function definitions of the functions used in the setup. Nothing new here, apart from the startWebSocket function. You
just have to start the WebSocket server using the begin method, and then give it a callback function that is executed when the ESP
receives a WebSocket message.
Server handlers
This is the code that is executed on certain server-related events, like when an HTTP request is received, when a file is being
uploaded, when there's an incoming WebSocket message ... etc.
void handleNotFound(){ // if the requested file or page doesn't exist, return a 404 not found error
if(!handleFileRead(server.uri())){ // check if the file exists in the flash memory (SPIFFS), if so, send it
server.send(404, "text/plain", "404: File Not Found");
}
}
bool handleFileRead(String path) { // send the right file to the client (if it exists)
Serial.println("handleFileRead: " + path);
if (path.endsWith("/")) path += "index.html"; // If a folder is requested, send the index file
String contentType = getContentType(path); // Get the MIME type
String pathWithGz = path + ".gz";
if (SPIFFS.exists(pathWithGz) || SPIFFS.exists(path)) { // If the file exists, either as a compressed archive, or normal
if (SPIFFS.exists(pathWithGz)) // If there's a compressed version available
path += ".gz"; // Use the compressed verion
File file = SPIFFS.open(path, "r"); // Open the file
size_t sent = server.streamFile(file, contentType); // Send it to the client
file.close(); // Close the file again
Serial.println(String("\tSent file: ") + path);
return true;
}
Serial.println(String("\tFile Not Found: ") + path); // If the file doesn't exist, return false
return false;
}
void handleFileUpload(){ // upload a new file to the SPIFFS
HTTPUpload& upload = server.upload();
String path;
if(upload.status == UPLOAD_FILE_START){
path = upload.filename;
if(!path.startsWith("/")) path = "/"+path;
if(!path.endsWith(".gz")) { // The file server always prefers a compressed version of a file
String pathWithGz = path+".gz"; // So if an uploaded file is not compressed, the existing compressed
if(SPIFFS.exists(pathWithGz)) // version of that file must be deleted (if it exists)
SPIFFS.remove(pathWithGz);
}
Serial.print("handleFileUpload Name: "); Serial.println(path);
fsUploadFile = SPIFFS.open(path, "w"); // Open the file for writing in SPIFFS (create if it doesn't exist)
path = String();
} else if(upload.status == UPLOAD_FILE_WRITE){
if(fsUploadFile)
fsUploadFile.write(upload.buf, upload.currentSize); // Write the received bytes to the file
} else if(upload.status == UPLOAD_FILE_END){
if(fsUploadFile) { // If the file was successfully created
fsUploadFile.close(); // Close the file again
Serial.print("handleFileUpload Size: "); Serial.println(upload.totalSize);
server.sendHeader("Location","/success.html"); // Redirect the client to the success page
server.send(303);
} else {
server.send(500, "text/plain", "500: couldn't create file");
}
}
}
void webSocketEvent(uint8_t num, WStype_t type, uint8_t * payload, size_t lenght) { // When a WebSocket message is received
switch (type) {
case WStype_DISCONNECTED: // if the websocket is disconnected
Serial.printf("[%u] Disconnected!\n", num);
break;
case WStype_CONNECTED: { // if a new websocket connection is established
IPAddress ip = webSocket.remoteIP(num);
Serial.printf("[%u] Connected from %d.%d.%d.%d url: %s\n", num, ip[0], ip[1], ip[2], ip[3], payload);
rainbow = false; // Turn rainbow off when a new connection is established
}
break;
case WStype_TEXT: // if new text data is received
Serial.printf("[%u] get Text: %s\n", num, payload);
if (payload[0] == '#') { // we get RGB data
