ESP8266 First Web Server
The actual implementation of a web server is much easier than it sounds, because the ESP8266 Arduino Core includes some great
libraries that handle pretty much everything for you. Let's look at a basic Hello World! example.
#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WiFiMulti.h>
#include <ESP8266mDNS.h>
#include <ESP8266WebServer.h> // Include the WebServer library
ESP8266WiFiMulti wifiMulti; // Create an instance of the ESP8266WiFiMulti class, called 'wifiMulti'
ESP8266WebServer server(80); // Create a webserver object that listens for HTTP request on port 80
void handleRoot(); // function prototypes for HTTP handlers
void handleNotFound();
void setup(void){
Serial.begin(115200); // Start the Serial communication to send messages to the computer
delay(10);
Serial.println('\n');
wifiMulti.addAP("ssid_from_AP_1", "your_password_for_AP_1"); // add Wi-Fi networks you want to connect to
wifiMulti.addAP("ssid_from_AP_2", "your_password_for_AP_2");
wifiMulti.addAP("ssid_from_AP_3", "your_password_for_AP_3");
Serial.println("Connecting ...");
int i = 0;
while (wifiMulti.run() != WL_CONNECTED) { // Wait for the Wi-Fi to connect: scan for Wi-Fi networks, and connect to the strongest of
the networks above
delay(250);
Serial.print('.');
}
Serial.println('\n');
Serial.print("Connected to ");
Serial.println(WiFi.SSID()); // Tell us what network we're connected to
Serial.print("IP address:\t");
Serial.println(WiFi.localIP()); // Send the IP address of the ESP8266 to the computer
if (MDNS.begin("esp8266")) { // Start the mDNS responder for esp8266.local
Serial.println("mDNS responder started");
} else {
Serial.println("Error setting up MDNS responder!");
}
server.on("/", handleRoot); // Call the 'handleRoot' function when a client requests URI "/"
server.onNotFound(handleNotFound); // When a client requests an unknown URI (i.e. something other than "/"), call function
"handleNotFound"
server.begin(); // Actually start the server
Serial.println("HTTP server started");
}
void loop(void){
server.handleClient(); // Listen for HTTP requests from clients
}
void handleRoot() {
server.send(200, "text/plain", "Hello world!"); // Send HTTP status 200 (Ok) and send some text to the browser/client
}
void handleNotFound(){
server.send(404, "text/plain", "404: Not found"); // Send HTTP status 404 (Not Found) when there's no handler for the URI in the
request
}
There's a lot of code that's the same as in the Wi-Fi and mDNS examples.
The actual server code is pretty straightforward. First, we create a server instance that listens for HTTP requests on port 80. This is the
default port for web servers. In the setup, we tell the server what to do with certain HTTP requests. If the URI '/' is requested, the
server should reply with a HTTP status code of 200 (Ok) and then send a response with the words 'Hello world!'. We put the code for
generating a response in a separate function, and the we tell the server to execute it when '/' is requested, using the
function.
We haven't specified what the server should do if the client requests any URI other than '/'. It should respond with an HTTP status 404
(Not Found) and a message for the user. We put this in a function as well, and use
when it receives a request for a URI that wasn't specified with
Then we start listening for HTTP requests by using
During the loop, we constantly check if a new HTTP request is received by running
requests, it will automatically execute the right functions that we specified in the setup.
To test it out, upload the sketch, open a new browser tab, and browse to http://esp8266.local. You should get a webpage saying
. If you try to go to a different page, http://esp8266.local/test, for instance, you should get a 404 error:
world!
Turning on and off an LED over Wi-Fi
We can use the web server to serve interactive pages, and to react to certain POST request. In the following example, the ESP8266
hosts a web page with a button. When the button is pressed, the browser sends a POST request to /LED. When the ESP receives such a
POST request on the /LED URI, it will turn on or off the LED, and then redirect the browser back to the home page with the button.
In order to perform this redirect, the ESP has to add a Location header to the response, and use a 303 (See Other) HTTP status code.
The button to send the POST request in the browser is part of an HTML form. You have to specify the target URI to send the request to,
and the request method, in this case this is "/LED" and POST respectively.
Note that I changed the content type of the response from "text/plain" to "text/html". If you send it as plain text, the browser will
.
server.on
.
server.begin
to tell it that it should execute it
server.onNotFound
. If handleClient detects new
server.handleClient
404: Not found
server.on
Hello
.
