3 Specifications

3.1 Electrical specifications for standard configuration

FF-Fieldbus
Interface
Termination
Baud rate
Field bus ID (Node ID)
Default Tag Name
Execution Time
PD_TAG = Modbus_FF
Manufacture Id = 0x000105 hex - Microcyber Inc
Device Type = 0x1001 hex
DEV-Rev = 0x01 hex
DD-Rev=0x01 hex
CF-Rev = 0x01 hex
ITK-Rev = 5.00
DD-File - Tested on the following systems
- Emerson Delta V version 8.4.2
- Yokogawa Centum VPR 5.01
- Honeywell, Experion control system revision 400.2

3.2 Power Ratings

FF-Fieldbus – H1
Power Requirements: 9-32 V
Current Consumption: < 5mA
