Quick Start Guide
QFX3100
IN THIS GUIDE
Step 1: Begin | 1
Step 1: Begin
IN THIS SECTION
To install and configure a Juniper Networks QFX3100 Director device, you need:
One pair of adjustable rear mounting brackets (provided)
Screws to attach the mounting brackets to the chassis (provided)
Phillips (+) screwdriver, number 2, to remove and tighten screws
12 screws to secure the chassis and mounting brackets to the rack (not provided)
Advertisement
Table of Contents
Related Manuals for Juniper QFX3100
Summary of Contents for Juniper QFX3100
- Page 1 Connect Power to the QFX3100 | 3 Connect the QFabric System Control Plane and Data Plane | 4 To install and configure a Juniper Networks QFX3100 Director device, you need: One pair of adjustable rear mounting brackets (provided) Screws to attach the mounting brackets to the chassis (provided)
- Page 2 NOTE: The device weighs approximately 41.2 lb (18.7 kg). Installing the QFX3100 Director device in a rack or cabinet requires one person to lift it and a second person to secure it to the rack. 4. Have one person grasp both sides of the device, lift it, and position it in the rack, aligning the front bracket holes with...
- Page 3 5. Repeat Step 1 through Step 4 for the second AC power supply. 6. To power on the device, set the power switch on the back of the QFX3100 Director device to the ON (I) position. The power switch is located next to the power supplies.
- Page 4 Director device provides redundancy for the QFabric system control plane and management network. 2. Connect network module ports on the first QFX3100 Director device to the second Director device. See the QFabric system control plane example in the deployment guide for your QFabric system at https://www.juniper.net/documentation/en_US/junos/information-products/pathway-pages/qfx-series/qfabric-deployment.html.
- Page 5 Set Parameter Values After you power on the QFX Series device, you must perform the initial setup of the QFX3100 Director group. Before you begin, set the following parameter values in the terminal emulator software on your laptop or PC: Baud Rate—9600...
- Page 6 IP addresses you specified in the Director group installation script). For detailed information about these procedures, see the deployment guide for your QFabric system at https://www.juniper.net/documentation/en_US/junos/information-products/pathway-pages/qfx-series/qfabric-deployment.html. Step 3: Keep Going IN THIS SECTION Safety Warnings Summary | 7 Power Cable Warning (Japanese) | 7 Contacting Juniper Networks | 8...
- Page 7 See the complete QFX3100 documentation at https://www.juniper.net/documentation/en_US/release-independent/junos/topics/concept/qfxctrl-hardware-overview.html. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the QFX3100 documentation https://www.juniper.net/documentation/en_US/release-independent/junos/topics/concept/qfxctrl-hardware-overview.html. WARNING: Failure to observe these safety warnings can result in personal injury or death.
- Page 8 For technical support, see: http://www.juniper.net/support/requesting-support.html Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
