Effective Area
ASR
Pressure Valve / Series
Type
ASR430F-02-06S ( -F20 )
ASR430F-02-08S ( -F20 )
ASR430F-02-10S ( -F20 )
ASR530F-02-06S ( -F20 )
ASR530F-02-08S ( -F20 )
ASR530F-02-10S ( -F20 )
ASR530F-02-12S ( -F20 )
ASR530F-03-06S ( -F20 )
ASR530F-03-08S ( -F20 )
ASR530F-03-10S ( -F20 )
ASR530F-03-12S ( -F20 )
ASR630F-03-10S ( -F20 )
ASR630F-03-12S ( -F20 )
ASR630F-04-10S ( -F20 )
ASR630F-04-12S ( -F20 )
Operating principle
Working stroke
P
H
P
R
1. The cylinder starts smoothly because jerks are prevented by
meter-in control.
Working stroke
Return stroke
2. When the cylinder reaches the stroke end, the quick air charge
by the flow valve rapidly increases the rear side pressure (PH)
from A to B. If a speed controller is used instead of the flow
valve, charging air will take more time as illustrated by line A-
C, causing delay in the pressure rise.
Free flow
Controlled flow
2
2
mm
mm
5.4
5.9
5.9
6.7
5.9
6.7
7.3
8.1
8.9
11.8
9.2
13.3
9.5
13.7
7.3
8.1
8.9
11.8
9.2
13.3
9.5
13.7
15.3
17.8
16.0
19.1
15.3
17.8
16.0
19.1
B
C
A
P
R
P
H
Time
Jerk
prevention
Quick supply
ASR
Series
ASQ
Flow Valve / Series
Type
ASQ430F-02-06S ( -F20 )
ASQ430F-02-08S ( -F20 )
ASQ430F-02-10S ( -F20 )
ASQ530F-02-06S ( -F20 )
ASQ530F-02-08S ( -F20 )
ASQ530F-02-10S ( -F20 )
ASQ530F-02-12S ( -F20 )
ASQ530F-03-06S ( -F20 )
ASQ530F-03-08S ( -F20 )
ASQ530F-03-10S ( -F20 )
ASQ530F-03-12S ( -F20 )
ASQ630F-03-10S ( -F20 )
ASQ630F-03-12S ( -F20 )
ASQ630F-04-10S ( -F20 )
ASQ630F-04-12S ( -F20 )
Return stroke
D
F
P
R
E
P
H
3. To prevent delay due to the pressure gap, air is rapidly
exhausted to decrease the pressure from D to E, after which
the piston moves at a constant speed. If a speed controller is
used instead of the flow valve, exhausting air will take more
time as illustrated by line D-F, resulting in longer stop time of
the cylinder and a consequent time loss.
4. The cylinder operates at a low pressure required for a return.
Air Saving Valve
ASQ
/
Series
Meter-out
Meter-in
2
2
mm
mm
4.1
4.9
4.6
5.5
4.6
5.5
6.6
7.8
9.2
10.1
9.8
10.8
10.8
11.6
6.6
7.8
9.2
10.1
9.8
10.8
10.8
11.6
15.3
17.1
16.2
18.0
15.3
17.1
16.2
18.0
P
R
P
H
Time
Quick exhaust
Low pressure
operation
2
