SMC Networks ASR Series Instruction Manual page 4

Air Saving Valve
Pressure Valve
Series
Pressure valve / Series
Regulator with check valve and flow control
valve integrated into a single construction
Series ASQ
Flow valve /
Pilot valve and two-way flow control valve
integrated into a single construction
1
ASR /
ASR
ASR
Model
ASR
Pressure valve
ASQ
Flow valve
Body size
4 1/4 standard
5 3/8 standard
6 1/2 standard
3
Models
Pressure valve
ASR430F-02
ASR530F-02
ASR530F-03
ASR630F-03
ASR630F-04
Specifications
Proof pressure
Maximum operating pressure
Set pressure
range
Ambient and fluid temperature
Number of needle rotations
Applicable tubing material
Flow Valve
Series
How to Order
4 3 0 F 02
Type
Universal
With One-touch fitting
Model
Flow valve
ASQ430F-02
ASQ530F-02
ASQ530F-03
ASQ630F-03
ASQ630F-04
Variable
Fixed (optional)
ASQ
06 S F20
With sealant
Variable set pressure type
Nil
(0.1 to 0.3 MPa)
Fixed set pressure type
F20
(0.2 MPa)
Applicable
tubing O.D.
1)
06
6 mm
08
8 mm
10 10 mm
12 12 mm
Port size
1)
02
R1/4
03
R3/8
04
R1/2
1) Please refer below
Model Table for
possible combination.
Applicable tubing O.D. (mm)
Port size
6 8 10
R1/4
R1/4
R3/8
R3/8
R1/2
1.5 MPa
1.0 MPa
0.1 to 0.3 MPa
0.2 MPa
–5 to 60°C (with no freezing)
10 rotations
Nylon, Soft nylon, Polyurethane
Option
