Server IntelliServ IS-1/3 Manual page 9

WIRING
1
2
3
4
L2
5
L1
1 4
6
2 5
7
8
Cord Assembly
1
230V
A
B
C
2 Bushing/Strain Relief
3
Thermal Cutout
4
8" White Wire Assembly
5
8" Black Wire Assembly
6
Rocker Switch
7
6" White Wire Assembly
UNITS 86338, 86339, 86341 (CONTINENTAL. EURO, AU, UK)
A B C
L2
L1
T1 T2
L2 N
9
Blue
Brown
Yellow/Green
15
CHASSIS GROUND
CHASSIS GROUND
14
PROBE
T3 T6
H/L1 LOAD
11
10
8
6" Black Wire Assembly
9
6" White Wire Assembly
10
500W Heating Element
11
6" Black Wire Assembly
12
3/4 Hole Shorty Bushing
13
Thermistor Assembly
14
Temperature Controller
15
5" Green Wire Assembly
13
12
