Server IntelliServ IS-1/3 Manual page 7

WIRING
1
2
3
4
Cord Assembly
1
120V USA
A
B
C
2
Bushing/Strain Relief
3
Wire Nut
4
19" White Wire Assembly
5
6" White Wire Assembly
UNITS 86090, 86254, 86481 (120V)
A B C
T1 T2
L2 N
5
White
Black
Green
CHASSIS GROUND
10
PROBE
T3 T6
H/L1 LOAD
7
6
6
500W Heating Element
7
6" Black Wire Assembly
Thermal Cutout
8
9
Thermistor Assembly
10
Temperature Controller
11
3/4 Hole Shorty Bushing
8
9
11
Page 7
