Server IntelliServ IS-1/3 Manual page 8

WIRING
1
2
3
4
5
1
2
3
4
5
6
Page 8
UNIT 86479 (100V JAPAN)
A B C
L2 L2
L1 L1
T1
L2
6
Cord Assembly
100V JAPAN
Blue
A
Brown
B
Yellow/Green
C
Bushing/Strain Relief
Thermal Cutout
4" White Wire Assembly
6" Black Wire Assembly
6" White Wire Assembly
12
CHASSIS GROUND
CHASSIS GROUND
PROBE
T2 T3 T6
N H/L1 LOAD
8
7
7
8
9
10
11
12
11
10
9
500W Heating Element
6" Black Wire Assembly
3/4 Hole Shorty Bushing
Thermistor Assembly
Temperature Controller
5" Green Wire Assembly
