M-system Mini-M M2MNV Instruction Manual page 2

INSTALLATION
Loosen the fixing screw at the front of the unit in order to
separate the body from the base socket.
■ DIN RAIL MOUNTING
Set the base socket so that
its DIN rail adaptor is at
the bottom. Position the
upper hook at the rear side
of base socket on the DIN
rail and push in the lower.
When removing the socket,
push down the DIN rail
adaptor utilizing a minus
screwdriver and pull.
■ WALL MOUNTING
Refer to "EXTERNAL DIMENSIONS."
TERMINAL CONNECTIONS
Connect the unit as in the diagram below or refer to the connection diagram on the side of the unit.
■ EXTERNAL DIMENSIONS unit: mm (inch)
21.5 (.85) 10 (.39)
■ CONNECTION DIAGRAM
■ INTERLOCKING SWITCHING CONTROL
(single-pole contact)
1
A1-1
2
A1-2
4
A2-1
5
A2-2
3
SWITCHING
6
SW1
COMMAND
9
DIN Rail
35mm wide
Spring Loaded
DIN Rail Adaptor
84 (3.31)
114 (4.49)
• When mounting, no extra space is needed between units.
7
B1-1
8
B1-2
10
U(+)
POWER
11
V(–)
