SMALLTRACK USER GUIDE
• SMALLTRACK technical characteristics :
1) Dimensions : 123,5 x 76 x 33 mm (L x W x D), without bracket and cable
2) Weight : 440g
3) External power supply : Input DC 6-42V (1A)
4) External battery : Rechargeable 1800mAH Li-ion battery
5) Internal antennas Iridium, GPS
6) 3 axis G-force sensors : Inclinometer and accelerometer
SAT
RESCUE
GPS
LED turns green
Red LED when alarm
Green LED when the
during transmission
has been sent
GPS signal is locked
MEDICAL ALERT
MECHANICAL ALERT
Pushing the
RED
button,
ON-OFF-RESTART
Pushing the
GREEN button,
immediately informs the PC
"PWR" Green LED when the
immediately informs the PC
course that you are victim
power is turned on
course that you or another
or witness of an accident
competitor has a
that requires medical
mechanical problem.
assistance.
