Steam Installation - Defensor Mk4 Unit Fitting And Steam Installation

2.

Steam installation

2.1 Security instructions for steam installation
2.2 Survey of steam installation
Steam distribution head, horizontal mounting
Hose clamps
20
- All work on the steam installation must only be performed by qualified technical
personnel. The customer is responsible for checking their qualifications.
- Please observe the local regulations governing the provision of ventilation ducts
with steam humidification.
The following figure shows the steam installation to be provided by the customer.
Accessories available are indicated:
Steam distribution head (accessory "81–..."
resp. "Z257" to "Z258")
Steam hose (accessory "Z10")
Condensate hose (108.3001)
Steam distribution head, vertical mounting
Support (20.4081)
