Channel / Video Cover
This menu allows you to create privacy zone(s) if you want to partially cover some certain part of the image. You can create up to 4 privacy zones in any
size and location on the camera image. Enable the Privacy Zone and choose how many zones you need. The zone(s) appear as a "red box". Click the edge of
the red box and drag it to any size to create a privacy zone.
Choose the channel to configure
Enable or disable privacy zone
Channel / Motion Detection
This menu allows you to configure motion settings. When motion is detected by one or more cameras, the system can alert you by sending an email alert
and/or send push notifications to your mobile app.
Choose the channel to configure
Enable or disable motion detection
Set the sensitivity level. Level 1 the lowest
sensitivity level while level 8 is the highest
sensitivity level.
Motion Detection Area: The whole screen is marked for motion
detection (red blocks) as default. If you want to disable the motion
detection on a certain area, click the grid cursor and then drag the
mouse to highlight the scope to unmark the area into transparent
blocks. After setting is completed, click the "Save" button to make
the area setup effective.

Record menu

To configure general settings
Record / Encode
The number of frames per second the system will record
The camera automatically chooses the correct setting between CBR (constant bitrate) and
VBR (variable bitrate). Please do not change the settings manually
If you want to set the bitrate by yourself, then choose User-defined mode. If
you want to select the predefined bitrate, choose Predefined mode
This parameter corresponds to the speed of data transfer that the system will use to
IFrame is the frame that is used as the primary reference point that is compared to the
Choose the channel to configure
How large the recorded image will be
H.265 is default, H.264 to support older cameras
record video.
other frames in the stream
