- Page 1 BASCOM CLIENT User Manual...
- Page 2 Online Help Center Questions about your camera system? Please visit our online help center. Here you can find the most recent articles about how to operate your system. Visit: www.bascom.support...
- Page 3 1. Installing the software / How to login Step 1 Connect the recorder to the internet Connect the recorder with a networkcable to your modem or router (the ‘box’ from your internet). Use these connections: • On the recorder: Internet or WAN •...
- Page 4 2. Main view Menu Main View Access the live view of the cameras Remote Playback Access camera recordings Remote Setting Camera and recorder settings System config Software settings Streaming Quality If your internet is fast enough, you can use Main Stream. Otherwise, use Sub Stream or Mobile Stream Full Screen mode Set the live view to full screen.
-
Page 5: Search, Playback & Backup
3. Remote Playback Menu Search, Playback & Backup The playback function gives you the ability to search for and play previously recorded videos as well as snapshots. You have the choice of playing video that matches your recording schedule, manual recordings or motion events only. -
Page 6: Channel Menu
4. Remote Setting Channel menu Channel / Channel Delete channel Add channel manually Camera online Camera offline Channel / Live Choose the channel to configure Give a name to the camera Date format which needs to be displayed Time format which needs to be displayed Refresh Rate of the camera Transparency of the block behide the date/time Show the camera name in live view... -
Page 7: Record Menu
Channel / Video Cover This menu allows you to create privacy zone(s) if you want to partially cover some certain part of the image. You can create up to 4 privacy zones in any size and location on the camera image. Enable the Privacy Zone and choose how many zones you need. The zone(s) appear as a “red box”. Click the edge of the red box and drag it to any size to create a privacy zone. -
Page 8: Record / Channel
Record / Record Choose the channel to configure Choose the recording quality. If you choose Dualstream, the system will record in both Mainstream & Substream Enable or disable the record If this option is enabled, the system starts recording a few seconds before an alarm event (motion detection for example) occurs. -
Page 9: Alarm / Exception
Alarm / I/O You can connect external sensor I/O alarm devices to the system. Choose the I/O channel to configure There are 3 alarm types: Normally-Open, Normally-Close, and OFF. Choose the one to match your sensor type, or choose OFF to close the sensor trigger function The system can use its internal buzzer to emit an alarm tone. -
Page 10: Network Menu
Port configuration menu : Web Port: This is the port that you will use to log in remotely to the system (e.g. using the Web Client). If the default port 80 is already taken by other applications, please change it. -
Page 11: Network / Ddns
Network / DDNS This menu allows you to configure DDNS settings. The DDNS provides a static address to simplify remote connection to your system. To use the DDNS, you first need to open an account on the DDNS service provider’s web page. DDNS: Check to enable DDNS. -
Page 12: Network / Ftp
Network / FTP Click to enable FTP function Choose the encryptation mode Enter your FTP server IP address or domain name Enter the FTP port for file exchanges Enter your FTP server username Enter your FTP server user password Enter the default directory name for the FTP file exchanges Choose the resolution of the FTP upload Choose the quality of the FTP upload Choose the video stream type of the FTP upload... -
Page 13: Device Menu
Device menu Device / Disk Information about the Hard Drive Disk Use this option to overwrite the old recordings on the HDD when the HDD is full. For example, if you choose the option 7 days then only the last 7 days recordings are kept on the HDD. To prevent overwriting any old recordings, select OFF. -
Page 14: System Maintenance
System / Multi-User The system supports the following account types: ADMIN — System Administrator: The administrator has full control of the system, and can change both administrator and user passwords and enable/disable password protection. USER — Normal User: Users only have access to live viewing, search, playback, and other functions. -
Page 15: System Information
IP address, MAC address, firmware version and more. You will find the P2P ID & P2P QR code in the information page. You can scan this QR code with the mobile Bascom app to view your cam- eras on your smartphone or tablet.
