READ FIRST ABOUT BATTERY OPERATION!
BY OBSERVING A FEW SIMPLE RULES, YOU CAN EXTEND THE
LIFESPAN OF THE SEALED LEAD ACID (SLA) BATTERIES THAT
OPERATE YOUR AMPLIVOX BATTERY POWERED PORTABLE
PA SYSTEM OR ACCESSORY:
• ALWAYS STORE SLA BATTERIES IN A CHARGED
CONDITION WHEN REMOVED FROM SERVICE.
• FOR SLA BATTERIES IN STORAGE, APPLY A TOPPING
CHARGE EVERY SIX MONTHS.
• AVOID REPEATED DEEP DISCHARGES. THIS PRACTICE
WILL CUT THE LIFE OF THE BATTERY SIGNIFICANTLY.
• AVOID OPERATING SLA BATTERIES AT ELEVATED
AMBIENT TEMPERATURES.
• BATTERY STATUS INDICATOR - RED = NO BATTERY POW-
ER, YELLOW = ABOUT 3 HOURS LEFT. CHARGE BATTERY
OVERNIGHT FOR BEST RESULTS.
Thank you for choosing the SW800-96 TITAN from
AmpliVox Portable Sound Systems.
We are excited in introducing this truly unique system.
Our system combines flexibility with functionality.
Please refer to this user guide as you enjoy the
unique capabilities of another quality product from
AmpliVox Portable Sound Systems.
We encourage you to visit our website
www.ampli.com to register your product for its war-
ranty coverage, sign up to receive our newsletter,
download our catalog, and learn more about the com-
plete line of AmpliVox audio visual products, including
portable PA systems, and lecterns.
AmpliVox • 650 Anthony Trail Suite D, Northbrook, IL 60062 • Phone: (800)267-5486 • Fax: (800)267-5489 www.ampli.com
User Guide
SW800-96 TITAN WIRELESS
Battery Powered PA System
Photo may appear different then your actual unit.

TABLE OF CONTENTS

CONTROL / BACK PANEL ........................... 4
OPERATION .... ...................................... 5
FUSE..................................................... 5
AUDIO FUNCTIONS ..................................5
MEDIA PLAYER .... ................................. 5
WIRELESS PANEL RECEIVER .................6
WIRELESS DUAL RECEIVER .................. 9
OPTIONAL ACCESSORIES ......................10
TROUBLESHOOTING ........................... 10
WARRANTY .............................................. 11
