AmpliVox Power Pod SW245 User Manual

Wireless pa with usb / sd media player and swb245 with bluetooth receiver
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless PA with USB / SD Media Player and
SWB245 with Bluetooth Receiver
Thank you for choosing the SW245 / SWB245 Wireless PA
from AmpliVox Portable Sound Systems.
We are excited in introducing this truly unique system. Our
system combines flexibility with functionality. Please refer to
this user guide as you enjoy the unique capabilities of an-
other quality product from AmpliVox Portable Sound Sys-
tems.
We encourage you to visit our website www.ampli.com to
register your product for its warranty coverage, sign up to
receive our newsletter, download our catalog, and learn
more about the complete line of AmpliVox audio visual
products, including portable PA systems, and lecterns.
AmpliVox • 650 Anthony Trail Suite D, Northbrook, IL 60062 • Phone: (800)267-5486 • Fax: (800)267-5489 www.ampli.com
User Guide
Power Pod - SW245

TABLE OF CONTENTS

PACKAGE CONTENTS ............................................3
SPECIFICATIONS ..........................................................3
BATTERY COMPARTMENTS ............................................3
TOP PANEL LAYOUT ......................................................4
SIDE PANEL LAYOUT .................... ................................4
MP3 PLAYER ....................................................................5
WIRELESS MICROPHONES .......................................5
.........................................6
TROUBLESHOOTING. .......................................................7
.
WARRANTY ............................................................8
.........................................6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Pod SW245 and is the answer not in the manual?

Questions and answers

Related Manuals for AmpliVox Power Pod SW245

Summary of Contents for AmpliVox Power Pod SW245

  • Page 1 BLUETOOTH RECEIVER …………………………….…….6 more about the complete line of AmpliVox audio visual TROUBLESHOOTING............7 products, including portable PA systems, and lecterns. WARRANTY …………………………………………….…..…8 AmpliVox • 650 Anthony Trail Suite D, Northbrook, IL 60062 • Phone: (800)267-5486 • Fax: (800)267-5489 www.ampli.com...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Before using this product, read the instruction manual for important safety information. Please retain this manual for future reference and warranty information. Troubleshooting & Servicing Do not attempt to service or repair the device yourself. Refer all servicing to qualified service personnel. Do not at- tempt to modify the device in anyway.

  • Page 3: Package Contents

    PACKAGE CONTENTS SPECIFICATIONS SW245 Amplified Speaker Rated Power Output: 50 W Dynamic  Wireless Handheld Microphone AC Power: 110 V  Wireless Transmitter Wireless Range: 61 to 128 ft.  Lapel Microphone VHF Wireless Frequency: 165 - 265 MHz  Headset Microphone Speaker: 6 1/2"...

  • Page 4: Top Panel

    TOP PANEL Wireless Microphone Volume Control – Adjust ③ MICROPHONE BATTERY ④ output loudness of wireless microphone. WIRED MICROPHONE CHARGE INDICATOR VOLUME CONTROL Power Indicator - LED lights when power is ② POWER INDICATOR turned on. ⑤ MICROPHONE JACK Microphone Battery Charge Indicator - LED ①...

  • Page 5: Mp3 Player

    MP3 PLAYER LED STATUS Charge Indicator - will light when main SLA battery is being charged. Mode - will light when SD/USB is being used. A - B - will light when programing repeat function. REC - will light when recording to a SD/USB device. Play/Pause - will light when SD/USB device is playing or flashing when paused .

  • Page 6: Operating Instructions

    WIRELESS MICROPHONE — continued TIPS  Take care in selecting volume level, and speaker placement so that acoustic feedback (howling and screeching) will be avoided. PA should be placed in front of person using microphone.  Also, microphones that are farther from the sound source, such as lapel, require more acoustic gain and thus are also more prone to feedback than close-source microphones such as handheld or headset microphones that are used close to the mouth.

  • Page 7: Troubleshooting

    TROUBLESHOOTING GUIDE PROBLEM & ITEMS TO CHECK UNIT WILL NOT TURN ON  Is unit plugged in?  Is the battery charged? SOUND IS DISTORTED  Turn down main volume  Turn down input source since the output of some devices may be too high SOUND IS MUFFLED ...

  • Page 8: Warranty

    RA#, the defective unit is to be returned to AmpliVox in either its original packaging or packaging affording an equal degree of protection. You will bear the cost of shipping the product to AmpliVox. If the product is covered by the warranty, AmpliVox will bear the cost of shipping product back to you after the completion of service under this warranty.
