Self-Test Function - LaserLiner DampMaster Data Plus Manual

19
To record measured data/measuring mode
Depending on the presetting, the measured data can be stored in two different ways. In the „AUTO" preset-
ting, the selection of the location marker (1 to 20) is shown on the display as soon as the measured value is sta-
ble. The corresponding location is set with the arrow keys. After a few seconds, the value is automatically saved
to the required location without the need for confirmation. On the other hand, in the „Location" presetting,
after selection the location is saved by manual confirmation with the „MODE" button. In both cases, the save
procedure can be cancelled by pressing the „ON/OFF" button.
AUTO
Location
The location marker can be assigned to a certain location (e.g. basement) and does not refer to
!
the number of available storage locations. The measured values are stored chronologically in each
location.
20

Self-test function

2 sec
1.
20.a
2.
20.b
DampMaster Data Plus
+
2 sec
21
GB
