5 - OPTIONS

a) Tab option

SIDE LAYGAUGE FOR TABS WITH THREE SOLENOIDS
SHEET SIZE
FAISABILITY ONLY ON
MAXIMUM HEIGHT OF
TABS
MIN. NUMBER OF TABS
MINIMUM SIZE
of the margin from the edge of the
sheet
UNFAISABILITY
SIZE OF SHEETS
- The second solenoid has to be located in the middle of the sheet to balance the laygauge.
- The laygauge with three solenoids is made possible by the low pressure of the solenoids, which
enables not to damage the sheets.
st
1 sheet
1 2 3
Assembly : remove the square of side laygauge to replace by the Tab Option by using a 6-face
key to remove the two screws. Connect the two electric wires on the little terminal located on the
support.
Disconnect the machine before operate
FOR ALPHA-DOC MAC 3
TECHNICAL SPECIFICATIONS
ROUND CORNERING TWO
12,7 mm
ROUND CORNERING ONE
Sheets between each index card
must have the same sizes as the
basis of the tab (size X) and the
same length (dimension Y) with a
0.2mm bracket.
ADVANTAGES
EXAMPLES
nd
2 sheet
Two solenoids have to be always in jogging operation to
ensure the pushing of sheets.
A4 P
US P
SIDES
4
0 mm
SIDE
rd
3 sheet
297 x 210 mm
279,4 x 215,9 mm
H max.
Y
th
4 sheet
