UM380
WATERPROOF DSC MARINE RADIO
RADIO MARITIME ASN HYDROFUGE
RADIO MARÍTIMA DSC IMPERMEABLE
OWNER'S MANUAL
GUIDE D'UTILISATION
GUÍA DE UTILIZACIÓN

Advertisement

loading

  Also See for Uniden UM380

  Related Manuals for Uniden UM380

  Summary of Contents for Uniden UM380

  • Page 1 UM380 WATERPROOF DSC MARINE RADIO RADIO MARITIME ASN HYDROFUGE RADIO MARÍTIMA DSC IMPERMEABLE OWNER’S MANUAL GUIDE D’UTILISATION GUÍA DE UTILIZACIÓN...
  • Page 2 Making a Distress Call Lift the red cover. Press and hold the button for three seconds. Your radio transmits your boat’s location every few minutes DISTRESS until you receive a response. nOte: if the radio displays Enter User MMSI, cancel the automatic distress call and make a normal voice distress call.
  • Page 3 Faire un appel De Détresse Soulevez le couvercle rouge. Maintenez la touche DISTRESS enfoncée pendant trois secondes. Le UM380 transmet la position de votre bateau à intervalles réguliers de quelques minutes, jusqu’à ce que vous receviez une réponse. Soulevez le couvercle rouge reMarQue : si la radio affiche enter user MMsi (entrer l’isMM de...
  • Page 4 CóMO haCer una llaMaDa De apurO Levante la tapa roja. Mantenga oprimido el botón por tres segundos. La radio transmitirá la localidad de su nave cada cuantos DISTRESS minutos hasta que reciba una respuesta. nota: si la radio exhibe (Inserte el MMSI del usuario), cancele la llamada de apuro automática y haga una llamada de apuro normal por voz.
  • Page 5 Contents Setting the volume ...... 11 Making a Voice Setting the squelch level ....11 Distress Call ..Inside front cover Changing the channel ....12 Faire un appel de détresse Making a transmission ....12 vocal ....Couverture avant Boosting the transmission power . 12 Cómo hacer una llamada de apuro Choosing Triple Watch or Dual por voz ....Tapa delantera...
  • Page 6 Disabling automatic channel US Marine Channels and switching ........26 Frequencies ........ 36 installing the hardware ....27 Canadian Marine Channels and Frequencies ........ 37 Mounting the radio ..... 27 International Marine Channels and Connecting the radio ....28 Frequencies ........ 39 Connecting to a GPS receiver ..
  • Page 7 intrODuCtiOn Submersible Design - Complies with JIS8 water-resistant standards, which means the Features radio can be submerged in 1.5 meter of water for 30 minutes without damage. Large, dot matrix display Advanced DSC Class D functions, including Test Calling Memory scan mode - Lets you save channels to memory and monitor them in quick succession.
  • Page 8 getting starteD What’s included Mounting Bracket and Mounting Hardware Microphone Hanger and Knobs Mounting Hardware English...
  • Page 9 parts of the radio VOLUME-PWR (power) knob (turn clockwise ENT- to increase display CHANNEL UP & 1W/25W volume) CHANNEL DOWN button button Microphone cord CLR-SCAN SQUELCH knob CALL- (channel (turn clockwise to MENU scan) button decrease channel button noise) DISTRESS button 16/9-TRI WX-MEM...
  • Page 10 Antenna Accessory Heat sink connector cable (SO238) Red wire ANTENNA 13.8V DC Black wire Power Cable Connector/Cable Connects to... For details, see ... External VHF antenna with a male PL259 (SO238) connector and 50 Ω Antenna Connecting the radio impedance. Minimum 4 ft, 3dB rated connector (see page 34).
