Storch ProDist compact plus Manual page 94

Volume measurement
2
1
1 3
Press the button 2x. The (area) symbol is
3
2
shown in the display.
Press the button to measure the first distance
(e.g., length)
Press the button to measure the second distance
(e.g., width)
Press the button to measure the third distance
(e.g., height)
The result is automatically determined and shown in an
m
3
format.
Indirect measurement (Pythagoras)
- Determining a distance with two measurements
Indirect measuring is used to measure distances that can-
not be measured directly because an obstacle would block
the laser beam, or there is no suitable target surface as a
reflector.
Indirect measurement for determining a distance with two
auxiliary measurements.
Press the button until the symbol appears
in the display. The distance to measure first is shown as a
flashing line in the symbol.
Original instruction
94
