Please read all instructions before installing
SPECIFICATIONS
Voltage ...............................................................120VAC, 60HZ
Load (Single Pole Circuit)
Incandescent or fluorescent lamp .................. 0 — 600 Watt
Fan motor .................................................................. 1/6HP
Time Delay..............................................5 minutes to 12 hours
Environment .................................................... Indoor use only
Operating Temperature ............... 32° to 104°F (0° to 40°C)
Humidity ...................................... 95% RH, non-condensing
Tools Needed
Insulated Screwdriver
Wire Strippers
Programmable Countdown
RT-100
Time Switch
Santa Clara, CA 95050
Advertisement
Table of Contents
Related Manuals for wattstopper RT-100
Summary of Contents for wattstopper RT-100
- Page 1 Please read all instructions before installing RT-100 Time Switch Programmable Countdown SPECIFICATIONS Voltage ...............120VAC, 60HZ Load (Single Pole Circuit) Incandescent or fluorescent lamp ....0 — 600 Watt Fan motor ..............1/6HP Time Delay..........5 minutes to 12 hours Environment ............ Indoor use only Operating Temperature ....
- Page 2 DESCRIPTION AND OPERATION The RT-100 is a time switch that turns OFF the connected light or fan (load) when the selected time expires. While the switch is OFF the pilot light behind the ON/ OFF button illuminates and “OFF” appears in the display. When the switch is ON, the display shows the amount of time the load will remain ON.
- Page 3 If a proper ground is not available, consult with a qualified electrician before continuing installation. Only connect the RT-100 to a Single Pole Circuit. The RT-100 is not suitable for 3-way switching. If the existing wiring does not match the description for a Single Pole Circuit, you should consult with a qualified electrician.
- Page 4 • Connect the NEUTRAL wires from the circuit to the white wire on the RT-100. 5. Put the RT-100 in the wall box with the display positioned above the ON/OFF button. Secure it to the wall box with the screws provided.
- Page 5 On to Off. For the Delay setting, when you reach 5:00 (5 minutes), pressing Lower brings the display to 1200 (12 hours). Programming Menu: Delay 5:00 minutes to 1200 hours Select Menu Lower Save Raise ON or off 06xxxr1 Flash on or off return to normal operation INDOOR USE ONLY www.wattstopper.com...
- Page 6 Delay Setting the initial time 1. Press the Menu/Raise button ONCE to see the current Delay setting. The factory setting for the Delay is 5 minutes, the minimum setting. 2. To change the setting, press the Select/ Save (middle) button. 5:00 3.
- Page 7 • Press the ON/OFF button. If the connected light or fan does not turn OFF, press the button and hold it a second longer. • Turn OFF power to the circuit then check wire connections. COVER PLATES WattStopper RT wall switches fit behind industry standard decorator style switch cover plates. www.wattstopper.com...
- Page 8 WARRANTY INFORMATION WattStopper warranties its products to be free of defects in materials and workmanship for a period of five (5) years. There are no obligations or liabilities on the part of WattStopper for consequential damages arising out of, or in connection with, the use or performance of this product or other indirect damages with respect to loss of property, revenue or profit, or cost of removal, installation or reinstallation.
