EEI –2146/2147
CHAIR

STEP 1:

Please find the package of Legs (2&3) and hardware on the top of the seat.
Then put the Chair Body (1) upside down on a carpeted or padded area by two adults to
Make the corners fully visible .
Position one of Back Legs (3) at one of the four wooden corners.
Insert 2 pieces of Spring Washer ( ( ( ( B) ) ) ) , Flat Washer (C) into 2 pieces of Bolts ( ( ( ( A) ) ) ) as shown.
Then insert assembled 2 pieces of Bolts (A) into the corner to connect one piece of the Back Leg (3).
Use Allen Wrench (D) to tighten the Bolts (A) clockwise until secure.
Repeat the same steps for the remaining one piece of Back Leg (3) and two pieces of Front Legs (2).
3
3
1
D
C
B
A
A A
1
2
A A 2
Ax8 Bx8 Cx8 Dx1
Hardware & Tool required

STEP 2:

Carefully turn over the chair .
Assembly is completed. The chair is ready to enjoy now!
Customer Service 908-368-1025︱ ︱ ︱ ︱ www.modwayfurniture.com
