2. Montage

2.1 Package content

1) VS30W/VS30B thermostat
2) Short instruction
3) Mounting screws

2.2 Proper thermostat location

Please note:
The ideal position to thermostat mounting is about 1,5m under floor level far from heating or cooling sources.
Thermostat can't be exposed to sunlight or any extreme conditions like for example draft.
Because of fire and explosion risk there is not allowed to use thermostat in atmosphere of explosive gases and flammable liquids (eg coal dust). In case
if any of listed dangers occur you have to use additional protection measures – anti-dust and explosive gases (tight cover) or prevent their formation.
Furthermore, thermostat can't be used in condensation of water vapor conditions and be exposed to water action.
Wall mounting
Mounting: to mount thermostat you can use accesories included with the set (mounting screws). Remove back cover to mount the plate to the wall.
After this just attach thermostat to the plate right into designed holes in the plate. The VS30 thermostat has been designed for flush mounting in a
standard electrical box with a diameter of 60 mm.
1
Open the housing with a
screwdriver - as shown in
the pictures above.
6
1
3
2
Mount the plate to the
wall using mounting
screws, in the correct
direction.
2
3
After all, attach the thermostat
to the plate. Use the plastic
hinges and make sure that wires
are in the correct place with the
thermostat.
