ADC ProPatch Programmable Series Specification Sheet page 4

ProPatch
High-Density Patching Systems
Longframe Chassis and Jack Dimensions
17.1 mm
(.67")
117.5 mm
(4.626")
POS 1
43.7 mm
(1.718")
POS 33
17 mm
(.67")
117.6 mm
(4.63")
43.7 mm
(1.72")
w w w . a d c . c o m
Programmable Series
®
(rear view)
441.5 mm
(17.38")
(top view)
464.8 mm
(18.3")
482.1 mm
(18.98")
(front view)
Typical 1 RU 32-Position Panel
(rear view)
441.5 mm
(17.38")
(top view)
POS. 1
POS. 24
POS. 25
POS. 48
464.8 mm
(18.3")
482.1 mm
(18.98")
(front view)
Typical 1 RU 24-Position Panel
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Chassis ground
Isolation ground
Programming Switch
31.5 mm
(1.24")
POS 32
31.8 mm
(1.25")
POS 64
Chassis ground
Isolation ground
31.8 mm
(1.25")
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Circuit status icon identi er
with 3 colors included
(8 colors available)
15.88 mm
(.625")
92.7 mm
(3.65")
12.5 mm
(.492")
Longframe Jack
4
