ADC ProPatch Programmable Series Specification Sheet page 11

ProPatch
Accessories
Individual longframe and bantam plugs are available featuring low capacitance injection-molded
insulators and precision-machined brass or nickel-plated conductors for smooth insertion and best signal
performance. Wire connections are made via miniature screw terminals. These plugs provide the best fit
and performance to match ADC patch panels.
Longframe Audio Plugs
O r d e r i n g I n f o r m a t i o n
Description
Three-Conductor Longframe Plugs (field installable)
Single
Single
Single, nickel-plated
Looping Plugs – internal connections tie together corresponding tip,
ring and sleeve conductors to allow looping of jack circuits
Hole Plugs – for longframe panels to fill unused jack positions
Bantam Audio Plugs
O r d e r i n g I n f o r m a t i o n
Description
Three-Conductor Bantam Plugs
Single plug; attachable plug; two lugs, shell mounting
screw and two lug attachment screws supplied
Dual plug; attachable plug; four lugs, two shell mounting
screws and four lug attachment screws supplied
Looping Plugs – Used to "loop" or patch adjacent jack circuits;
plug conductors strapped internally; wired tip to tip, ring to ring
and sleeve to sleeve
Hole Plugs – For bantam panels to fill unused jack positions
Single Bantam Circuit Guard Plugs – To identify or block entry
to critical circuits; does not actuate circuit
w w w . a d c . c o m
Programmable Series
®
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Color
Red
Black
Black
Black
Black
Color
Red
Black
Black
Black
Red
Black
Red
White
Black
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Catalog Number
PJ051R
PJ051B
PJ051B-MN
PJ4
PJ29
Catalog Number
PJ777R
PJ777B
PJ778B
PJ746
PJ729R
PJ729B
PJ925R
PJ925W
PJ925B
