ProPatch
High-Density Patching Systems
Bantam and Longframe Chassis and Module Specifications
ELECTRICAL
Contact resistance:
Insulation resistance:
Dielectric withstanding:
Contact rating:
MECHANICAL
Mechanical shock:
Vibration:
Insertion force:
Withdrawal force:
Life:
ENVIRONMENTAL
Operating temperature:
Storage temperature:
Thermal shock:
Operating humidity:
Storage humidity:
Salt spray:
Moisture resistance:
MATERIALS
Chassis frame:
Jack frame:
Springs:
Contacts:
PC boards:
Sockets:
Switches:
Bantam Chassis and Jack Dimensions
17.1 mm
(.673")
108 mm
(4.25")
43.7 mm
(1.72")
Typical 1 RU 48-Position Panel
w w w . a d c . c o m
Programmable Series
®
0.020 W max (initial)
0.020 W max (after life cycling)
0.10 W max (after salt spray)
10,000 MW min (initial)
1,000 MW min (after moisture resistance test)
Voltage: 500 Vac
Max: 100 mA + 130 Vdc; Min: -40 dBm
Per MIL-STD-202F, Method 213B, test condition H
MIL-STD-1344, Method 2005, test condition I
7 lbs (3.17 kg) max
1.5 lbs (.679 kg) min
20,000 insertion/withdrawal cycles min
-40° to 65°C (-40° to 149°F)
-55° to 85°C (-67° to 185°F)
Per MIL-STD-202F, Method 107G, test condition A
0% to 95% (no condensation)
0% to 95% (no condensation)
Per MIL-STD-202F, Method 101D
Per MIL-STD-202F, Method 106E
Steel, zinc plated with electroless nickel plating
Unreinforced polyetherimide resin rated UL 94-V0 for flammability
Nickel-silver
WECO No. 1 gold crossbar alloy welded to springs
FR-4
Phosper bronze
30 micro inches gold on contact
Copper alloy
10 micro inches min gold on contact
442 mm
(17.4")
(top view)
465.3 mm
(18.32")
482.6 mm
(19")
(front view)
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Programming Switch
30 mm
(1.2")
2.3 mm
(.09")
84 mm
31.8 mm
(3.3")
(1.25")
Bantam Jack
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Circuit status icon identi er
with 3 colors included
(8 colors available)
8 mm
(.312")
7.5 mm
(.295")
