- Page 1 John Lewis Felix 1 Drawer Bedside Oak Stock Number: 803 5001 H53 W40 D40 cm...
- Page 2 Thank you for purchasing the Felix 1 Drawer Bedside Oak. Please read the instructions and warnings carefully before use, to ensure safe and satisfactory operation of this product. At John Lewis, we are committed to making great product possible. From our in-house Design Team, to our Buyers, we work together to bring great design to life.
- Page 4 Your Bedside Cod. Description Dimensions 396mm x 280mm x 18mm CS2960 Drawer Drawer Bottom 350mm x 324mm x 3mm SH3112 350mm x 200mm x 12mm OS0230 Left Rail Drawer 350mm x 200mm x 12mm OS0229 Right Rail Drawer 313mm x 199mm x 12mm OS0231 Back Rail Drawer 402mm x 402mm x 18mm...
-
Page 5: Fixtures And Fittings
Fixtures and fittings Fixtures and fittings supplied (actual size) Cod. Description Dimensions FT0028 Cam Rods 7mm x 45mm Cam Heads FT0098 15mm x 10mm FV0005 Screw 3,5mm x 15mm Screw FV0137 4mm x 25mm Screw FV0109 3,5mm x 16mm Wooden Dowels FH0001 8mm x 30mm Screw... -
Page 6: Product Assembly
Product Assembly Felix 1 Drawer Bedside Oak 80315001 Step 1 Parts, fixing and tools Step 2 Parts, fixing and tools... - Page 7 Felix 1 Drawer Bedside Oak 80315001 Step 3 Parts, fixing and tools Step 4 Parts, fixing and tools...
- Page 8 Felix 1 Drawer Bedside Oak 80315001 Step 5 Parts, fixing and tools Step 6 Parts, fixing and tools...
- Page 9 Felix 1 Drawer Bedside Oak 80315001 Step 7 Parts, fixing and tools Step 8 Parts, fixing and tools...
- Page 10 Felix 1 Drawer Bedside Oak 80315001 Step 9 Parts, fixing and tools Step 10 Parts, fixing and tools...
- Page 11 Felix 1 Drawer Bedside Oak 80315001 Step 11 Parts, fixing and tools Step 12 Parts, fixing and tools...
-
Page 12: Safety Instruction
It is possible to obtain from the distributor any additional or replacement part. The Bedside is designed to be dismantled for storage or transportation. This Bedside conforms to BS 4875-7:2006 + BS EN 14749:2005 WARNING! Not suitable for children under 4 years. John Lewis Partnership 171 Victoria Street London SW1E5NN Johnlewis.com...
