7. Appendix

Technical details

Connections:
Ribbon cable adapter for Doepfer bus +/-12Volt
Inputs: 3x CV (0..+10v), 4x Trigger (0/+5..10v), 1/8th inch mono jacks
Outputs: 5x CV (0..+10v) 1V/Octave, 1/8th inch mono jacks
Current consumption: ca. +130mA / -20mA
Size: Euro rack format 3U / 10HP 40 x 128,5 x 50mm

Warrenty

Beginning from the date of purchase a 2-year warranty is guaranteed for this device in case of
any manufacturing errors or other functional deficiencies during runtime.The warranty does not
apply in case of:
- damage caused by misuse
- mechanical damage arising from careless treatment (dropping, vigorous shaking, mishandling, etc)
- damage caused by liquids penetrating the device
- heat damage caused by overexposure to sunlight or heating
- electric damage caused by improper connecting
(wrong power supply/ jacks/ MIDI connections/ voltage problems).
If you have any complaints please contact your dealer or send an e-mail to:
service@flame.fortschritt-musik.de

Terms of production

conformity: CE, RoHS, UL

Disposal

The device is produced with RoHS-conformity (subject to the regulations of the European Union)
and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
But electronical scrap is hazardous waste. Please don't add this to consumer waste. For an
environment friendly disposal of waste please contact your distributor or specialist dealer.

Support

Updated and additional informations, updates, downloads and more see:
http://flame.fortschritt-musik.de

Acknowledgment

For help and assistance big thanks to: Schneiders Büro Berlin, Shawn Cleary (Analogue haven,
Los Angeles), Robert Junge, Anne-Kathrin Metzler, Lena Bünger, Daniel Dorsch and Ebotronix.
11
