- Page 1 MINI RADIUS 1W RGB RGB Animation Laser User Manual LCG-256 1W RGB Please read this manual carefully before use!
-
Page 2: Table Of Contents
Animation Laser User Manual Contents Introduction--------------------------------------------------------------------------------------------------P2 Silkscreen on product------------------------------------------------------------------------------------P3 Safety instruction/Installation/Technical specification----------------------------------------P4 SD control system/Menu--------------------------------------------------------------------------------P5 DMX512 Channel------------------------------------------------------------------------------------------P6 DMX Address setting/DMX512 connection---------------------------------------------------------P7 Product size-------------------------------------------------------------------------------------------------P8 Ringing--------------------------------------------------------------------------------------------------------P9 Cleaning and maintenance/Warning/Warranty card-------------------------------------------P10 - - 1 - -... -
Page 3: Introduction
Animation Laser User Manual Introduction Thank you for purchasing this product. To optimize the performance of this product,prior to use,please read these operating instructions carefully to familiarize yourself with the basic operation of this unit.Please keep the manual in safe price for future reference. This unit has been tested at our factory before being shipped to you, there is no assembly required. - Page 4 Animation Laser User Manual Symbol Instruction On The Device -------------------------------------------------------------------------------CE Certificate ---------------------------------------------------------------------Only indoor use ------------------------------------------------------------------------Environmental protection ----------------------------------------The minimum distance from lighted objects(meter) ------------------------------------------------------------Max. Ambient Temp ----------------------------------------------------Max. Housing Temp ------------------------------------------------------------------------- Safety caution -------------------------------------------------------------------------Careful burns ------------------------------------------------------------------------Careful electric shock -----Not suitable for directly installed on the surface of ordinary combustible materials - - 3 - -...
- Page 5 Animation Laser User Manual Safety Instructions Please open and check whether break or not for transport once receive this fixture, if yes, not use it and contact dealer or manufacture as soon as possible. The Max applicable temperature for the light is 40°C. Do not use the light under or above the temperature.
-
Page 6: Dmx Address Setting/Dmx512 Connection
Animation Laser User Manual Carton packing size: 30*25*26cm SD laser control system 1. MENU operation Rotate the knob at display’s right side to operate the menu, press knob to enter sub-menu or exit menu, after operation, Non-stop double-click the knob to save the option and exit the menu.(Eg: when setting DMX address should Non-stop Double click the knob and exit MENU, then DMX address can successed save) The potentionmeter at display’s left side can adjust the power of laser: Red Current( adjust red... - Page 7 Animation Laser User Manual DMX Channel Instructions Channel Value Function auto mode 0-49 50-99 sound activated mode control mode 100-149 PRG file display orderly 150-199 ILD file display circularly 200-255 DMX Mode DMX Mode PRG/ILD mode choose 0-255 pattern/file choose pattern, 1 pattern for 3 digits choose file no strobe 0-10...
- Page 8 Animation Laser User Manual 201-255 zoom circularly no rotation Horizontal manual adjust 1-128 rotation 129-255 auto rotation no rotation Vertical CH10 1-128 manual adjust rotation 129-255 auto rotation no rotation manual adjust 1-128 CH11 center rotation 129-192 auto rotation clockwise 193-255 auto rotation anti-clockwise 0-10...
-
Page 9: Product Size
Animation Laser User Manual DMX In To the fourth First light (Address 001) Second light (Address 018) Third light(Address 035) DMX Address setting Each fixture must set a specific starting address. When receiving signal transmission, fixture will receive channel control signals which from the starting address. According to different requirements or easy to use, the user can set many value fixtures to the same address, also can set up a separate address for every device. -
Page 10: Ringing
Animation Laser User Manual Ringing 1 Mounting bracket 2 Handle A).The ambient temperature range is 1°C--45°C, must never be exceeded. B).The installation of the projector has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation. -
Page 11: Cleaning And Maintenance/Warning/Warranty Card
Animation Laser User Manual Cleaning and maintenance Maintenance should be performed every 15-day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror. Always disconnect from the mains when the device is not in use or before cleaning it. Caution Make sure power off before cleaning and maintenance! Warning...
