ADC ProPatch Miniature Series Specification Sheet page 3

ProPatch
Super High-Density Coax Patching System
1.5 Rack Unit Super High-Density Coax Patch Panel
Features:
• High-density: 48 total jacks (2x48)
• Large designation strips: .680" designation on top and bottom
• Lightweight: Less then 1.4 Kg (3 lbs) total panel weight
SHDC Jack
Features:
• Switchable between terminating and non-terminating normalled-through
• Non-normalled jack offered in same jack housing, looping plug available for circuit patching
LCC
1.0/2.3
w w w . a d c . c o m
Miniature Series
®
Normalling AES Straight-Through HD
SHDC-LCC
SHDC-1023
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
SHDC-LCC-NN
SHDC-1023-NN
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Normalling HD
SHDC-LCC-HP
SHDC-1023-HP
