ADC ProPatch Miniature Series Specification Sheet page 6

ProPatch
Super High-Density Coax Patching System
O r d e r i n g I n f o r m a t i o n
Description
Super High-Density Coax Jacks
LCC
1.0/2.3 connectors
O r d e r i n g I n f o r m a t i o n
Description
LCP High-Performance Patch Cords
2 feet
3 feet
4 feet
6 feet
O r d e r i n g I n f o r m a t i o n
Description
Looping plug; LCP .48" Centers
w w w . a d c . c o m
Miniature Series
®
Normalling
Straight-Through
Normalling
Straight-Through
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
AES and Analog Video
High-Performance, HD
High-Performance, HD
AES and Analog Video
High-Performance
High-Performance
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
LCC Jack
Catalog Number
SHDC-LCC
SHDC-LCC-HP
SHDC-LCC-NN
SHDC-1023
SHDC-1023-HP
SHDC-1023-NN
LCP Patch Cords
Catalog Number
BK2VXM-LCP-LCP
BK3VXM-LCP-LCP
BK4VXM-LCP-LCP
BK6VXM-LCP-LCP
LCP Looping Plug
Catalog Number
LP-SHDC-480
6
