Elitegroup Computer Systems 748-A Manual page 10

Table of Mainboard Components
Label Component
AGP1 Accelerated Graphics Port (supports 1.5V AGP card only)
ATX1 Standard 20-pin ATX power connector
AUDIO1 Front audio connector
BAT1 Three volt realtime clock battery
BAKFAN1* Case fan connector 2
CASFAN1 Case fan connector
CDIN1 Primary CD-in connector
CNR1 Communications Networking Riser slot
CPU SOCKET Socket A for AMD Athlon processor
CPUFAN1 Cooling fan for CPU
DIMM1~ DIMM3 Three 184-pin DDR SDRAM
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
IR1* Infrared port
JP1 Clear CMOS jumper
PANEL1 Connector for case front panel switches and LED indicators
PCI1 ~ PCI5 Five 32-bit add-on card slots
RF1 IR Mouse header
SJ1* Single color LED header
SPEAKER1 Speaker connector
USB3 Connector for front panel USB ports
USBCR1 USB Card reader connector
*Optional component
This concludes Chapter 1. The next chapter explains how to install the main-
board.
6
