Charge the unit by inserting the wall-charger into the charging socket (lift the rubber
cover to insert the plug). The red LED on the unit will start flashing when charging
begins.
Allow the headset to charge until the unit stops flashing or the blue LED turns on.
When the charge is complete (the red LED is not flashing), release the headset from
the charger. Normally, after the first time, it takes 2 hours for a full charge.
Attention: every time the micro USB recharging plug is inserted (or detached), the device
is automatically turned off. To use it while it is in charge, you should turn the device on with
the plug already inserted.
Unit and fixing system description
BTX2 PRO description
The BTX2 PRO has five buttons on the front; the main three big buttons are multi
functions buttons: the Forward (on the left), the middle button and the Backward (on
the right), the two squared buttons are the Volume + and Volume -.
Volume -
Forward Middle
Description of the wired connections
On the bottom of the unit you can find the Charger jack that enables to recharge the
unit using a standard microUSB power supply
The same micro USB charger plug can be used to connect an audio source, like a stereo
iPod/MP3 player;
Attention: you need an optional AUX cable not included in the box.
www.midlandeurope.com
Volume +
LED
Backward
Description of the audio kit
The audio system includes two ultra-flat stereo speakers and two interchangeable
microphones, which are both supplied with a bracket and wired connection. The mini
connector on the microphone allows you to choose the microphone that best suits the
helmet you are using.
Fixing the stereo speakers
The two stereo speakers have a Velcro/adhesive strip that aids their fixing into your
helmet. Beware not to completely cover your ear with the speakers, you must always
be able to listen to the traffic sound and your indicators.
The microphone can be fixed onto the helmet in two ways:
Boom Microphone
Place the section with the Velcro/adhesive strip between the padding and the rigid co-
ver of the helmet, so that the microphone is correctly positioned in front of your mouth
and that the white symbol is facing your mouth. This type of microphone is suited for
Open Faced and Flip Front helmets.
Charger plug
