Danger!
For thigh amputees you must use anti-tip tubes.
Danger!
Before setting off, check that your tyre pressure is correct. For rear
wheels it should be at least 3.5 bar ( 350 kPa). The max. pressure
is indicated on the tyre.
The knee-lever brakes will only work if there is sufficient tyre
pressure and if the correct setting has been made (see the
Chapter on "Brakes").
Danger!
The wheel locks are not intended to brake your wheelchair. They
are only there to ensure that your wheelchair does not begin rolling
unintentionally. When you stop on uneven ground, you should
always use the wheel locks to prevent such rolling. Always apply
both wheel locks; otherwise, your wheelchair could tip over.
Danger!
If the seat and back sling are damaged, you must replace them
immediately.
Danger!
Be careful with fire, in particular with burning cigarettes. Seat and
back slings can be set alight.
Danger!
If and whenever possible, during a journey in a specially fitted
vehicle for disabled people, vehicle occupants should use the
seats in the vehicle and the appropriate restraint system. This
is the only way to ensure that occupants will have the maximum
protection if there is an accident. When using safety elements
offered by SUNRISE MEDICAL and using a specially designed
safety system, lightweight wheelchairs can be used as a seat when
being transported in a specially fitted vehicle. (See the Chapter on
"Transportation").
Danger!
Always make sure that the quick-release axles on the rear wheels
are set properly and lock in. If the button on the quick-release axle
is not pressed in, the rear wheel cannot be removed.
Danger!
In particular when using lightweight metal handrims, fingers will
easily become hot when braking from a high speed or on long
inclines.
Danger!
If the wheelchair is subject to direct sunlight for a long period of
time, then parts of the wheelchair (e.g. frame, legrests, brakes and
sideguard) may become hot (>41°C).
Danger!
To avoid hand injuries do not grab in between the spokes
or between the rear wheel and wheel lock when driving the
wheelchair.
Danger!
Do not use the wheelchair on slopes > 10°.
The Dynamic safe slope is dependant on the chair configuration,
the users abilities and the style of riding. As the users abilities and
style of riding cannot be pre-determined then the max safe slope
cannot be determined. Therefore this must be determined by the
user with the assistance of an attendant to prevent tipping. It is
strongly recommended that inexperienced users have Ant-tips
fitted.
Do not use your wheelchair on muddy or icy ground.
Do not use your wheelchair where pedestrians are not allowed.
Note !
The effect of the knee-lever brake as well as the general driving
characteristics are dependant on tyre pressure. The wheelchair is
significantly lighter and easier to manoeuvre when the rear wheels
are pumped up correctly and both wheels have the same pressure.
Note !
Make sure that your tyres have sufficient tread!
Please note that you are subject to any and all traffic laws when
driving in public traffic.
Note !
When it is dark, please wear light clothing or clothing with
reflectors, so that you can be seen more easily. Make sure that the
reflectors on the side and back of the wheelchair are clearly visible.
We would also recommend that you fit an active light.
Note !
Always be careful with your fingers when working or adjusting the
wheelchair!
UniX Rev 1
The products shown and described in this manual may not be
exactly the same in every detail as your own model. However,
all instructions are still entirely relevant, irrespective of detail
differences.
The manufacturer reserves the right to alter without notice any
weights, measurements or other technical data shown in this
manual. All figures, measurements and capacities shown in this
manual are approximate and do not constitute specifications.
Lifetime
The expected lifetime of this product is 5 years.
Warranty
Guarantee
THIS IN NO WAY AFFECTS YOUR STATUTORY RIGHTS.
Warranty conditions
1) The repair or replacement will be carried out by an
authorised Sunrise Medical dealer/service agent.
2) To apply the warranty conditions, should your product
require attention under these arrangements, notify the
designated Sunrise Medical service agent immediately giving
full information about the nature of the difficulty. Should you be
operating the product away from the locality of the designated
Sunrise Medical service agent, work under the "Warranty
Conditions" will be carried out by any other service agent
designated by the manufacturer.
3) Should any part of the wheelchair require repair or
replacement, as a result of a specific manufacturing or material
defect, within 24 months (5 years on frame and cross brace)
from the date on which the possession of the product was
transferred to the original purchaser, and subject to it remaining
within that ownership, the part or parts will be repaired or
replaced completely free of charge if returned to the authorised
service agent.
Note: This guarantee is not transferable.
4) Any repaired or replaced part will benefit from these
arrangements for the balance of the warranty period applicable
to the wheelchair.
5) Parts replaced after the original warranty has expired are
covered for a further 24 months.
6) Items of a consumable nature will not generally be covered
during the normal warranty period, unless such items have
clearly suffered undue wear as a direct result of an original
manufacturing defect. These items include amongst others
upholstery, tyres, inner tubes and similar parts. On powered
products this will also include batteries, motor brushes etc.
7) The above warranty conditions apply to all product parts for
models purchased at full retail price.
8) Under normal circumstances, no responsibility will be
accepted where the product has required repair or replacement
as a direct result of:
a) The product or part not having been maintained or serviced
in accordance with the manufacturer's recommendations, as
stated in the Owner`s Manual and / or Service Manual. Failing
to use only the specified original equipment parts.
b) The product or part having been damaged by neglect,
accident or improper use.
c) The product or part having been altered from the
manufacturer's specifications, or repairs having been attempted
prior to the service agent being notified.
4
