Deck Housing Components
1
2110
Hood Latch Assembly
2
2786-4
Locking Finger
3
2786-1
Footrest, DSD60 (Includes Items # 4 & 5) 1
4
2786-3
Rubber Mat (2 x 7)
5
2786-2
Rubber Mat (7 x 9-1/2)
6
4845
Rubber Bumper (1.0 x .625)
7
2703-5
Knob, 10-24 x 1/2
8
2724-1
Spindle Cover
9
2731-1
Belt Guide Roller
10
5162-11
Roller Wheel (5") (Includes Item # F059)
11
8490
Roller Wheel Axle Bolt
12
NS
Deck Serial Number Plate
13
8735-10
Rubber Mat (5 x 6)
14
2910
60SD Deck Assembly / Tilt
15
2720-5
Deck Height Adjustment Clevis
16
6682-13
Axle Spacer
17
6715
Roller Wheel (3-7/8)
18
2725-5
Tensioner Mate
19
8910-5
Tie Down Strap
20
2705-4
End Backup Plate
21
2705-3
Center Backup Plate
22
2809-1
Rubber Shield
23
2705-6
Chute Frame / Outer
24
8670
Tilt-Up Hook
Blade Drive Components
25
2618-1
Cover, PTO Shaft Guard
26
2620-3
Rubber Flap
27
2620-2
Backing Plate
28
2619-1
PTO Shaft Guard
2618-2
PTO Shaft Guard Assembly
(Includes Items # 25-28, F002, F025 & F028)
29
5270
Bearing W/Collar (1")
30
2726
PTO Bearing Housing
31
2726-1
PTO Drive Shaft
32
2240-1
Drive Pulley
(Includes Items # F075 & F435)
33
2265
Bearing (20mm)
34
2245-4
Idler Pulley Shaft
35
2725-1
Tilted Idler Mount
36
8285-15
U-Joint Shaft Assembly, Spline
(Includes Item # F318)
37
4245-1
Idler Pulley (4/Flat)
38
2240
Blade Drive Pulley (3-1/2)
39
8245
Idler Pulley (6")
40
2350-5
Washer (3/8-16 Tap 1/4 Thk)
41
2731
Blade Drive Belt (R3VX1250)
42
5841
Retainer Washer (3/8 x 1-1/4)
43
2245-1
Idler Pulley
2245
Idler Pulley Assembly
(Includes Items # 33, 34, 43 & F445)
44
5830
Grease Fitting
45
7201-3
DU Bearing
Use only genuine Walker
74
DSD60 DECK ASSEMBLY (P/N 2910)
DESCRIPTION
®
replacement parts.
NO.
ITEM
PART
REQ'D
NO.
NO.
46
7201-5
47
2724-4
2
48
2350-4
2
49
2725-3
2
50
6235
51
2350-2
2
4
4
52
2350-3
53
2221
2
1
54
2724-3
2
Blade Spindle Components
55
2052
2
56
7705-11
1
2
Fasteners
F002
1
F004
2
F005
4
4
F009
F012
1
2
F013
F014
2
F025
1
1
F028
F029
1
F031
1
F033
F034
1
F039
1
F041
1
F043
1
F045
*
F048
F049
2
F050
1
F051
1
F055
1
F059
F067
1
F075
1
F108
1
F131
1
F206
F236
1
F241
3
F265
2
F268
2
F276
1
F318
1
F405
1
*
F408
F435
1
F445
*
2
Service Part Only
DESCRIPTION
Inner Race (2-1/4)
5/16 x 3/8 SHL Bolt
Washer (1/2 OD x 5/16 ID x .030)
Cam Tensioner
Spring, Belt Tension Cam
Idler Cam Spring Washer
(Includes Item # 52)
Idler Cam Washer (2" OD)
Extension Spring (1 x 4)
Idler Arm (Includes Item # 44)
Blade Spindle
Blade 20.5" (RH Rotation)
10-24 Keps Nut
1/4-20 Keps Nut
1/4-20 ESNA Nut
5/16-18 Whiz Locknut
3/8-16 Keps Nut
3/8-16 Whiz Locknut
3/8-16 ESNA Nut
10-24 x 3/8 PPHMS
10-24 x 3/4 PPHMS
1/4-20 x 1/2 Hex Bolt
1/4-20 x 5/8 Hex Bolt
1/4-20 x 1 PTH Bolt
5/16-18 x 3/4 Hex Bolt
3/8-16 x 1-1/4 Hex Bolt
3/8-16 x 1-3/4 Hex Bolt
3/8-16 x 3 Hex Bolt
3/16 x 3/16 x 3/4 Key
1/2 SAE Washer
5/16 SAE Washer
1/4 SAE Washer
3/8 SAE Washer
5/8 SAE Washer
3/8 Wave Spring Washer
3/16 x 3/16 x 1 Key
5/16-18 x 1/2 SQH Set Screw
3/8-16 x 2 Hex Bolt
5/16-18 x 1/2 Hex Bolt
#2 x 3/16 Drive Pin
1/4-20 x 1-3/4 Hex Bolt
.375 x .875 x .10 Washer
1/2-20 x 1-1/2 Hex Bolt
5/16-18 x 3 Hex Bolt
5/8-11 Jam Nut
3/8-16 x 3/4 SQH Set Screw
3/8-16 x 1-1/2 FHA Screw SS
7/16-20 Jam Nut
1/4 x 1/4 x 1-1/4 Key
1-7/8 Internal Snap Ring
Effective Date 03-31-08
NO.
REQ'D
1
1
1
1
1
1
1
1
1
3
3
12
8
8
14
2
24
2
10
2
4
4
8
6
18
3
1
3
3
2
3
2
3
4
1
2
1
2
2
1
2
3
4
3
1
2
2
1
1
