Tractor And Deck Decals - Walker MBSSD (27 HP) Owner's Manual

ITEM PART DESCRIPTION
NO. NO.
Walker Product and Operation Decals
1 2802-2 RH Fender
2 2010-4 Fuel Transfer
3 5800-6 Decal, Walker 6-3/4"
4 2802-1 LH Fender
5 9804 Axle Lockout
6 5856 Made in USA
7 5803 Walker Manufacturing Logo
8 2748 Cutting Height Adjustment
9 5800-5 Decal, Walker 8"
Danger Decals Warning Decals Caution Decals
10 5805 Caution, Engine Exhaust
11 6810 Danger, Engine Exhaust
12 2107-4 Decal, Belt Routing
13 4107-1 Danger, Rotating Components
14 5808 Danger, Rotating Blades
15 8647 Danger, Tilt-Up
16 8653-1 Transport Warning
17 8653 Caution, Pivot Joint
18 2749 Decal, Drive Belt Routing
19 5848 Danger, Side Discharge Shield
Maintenance Decals
20 2105-8 RH Decal, 27 HP
21 2105-9 LH Decal, 27 HP
22 5855 Important, Engine Cooling
23 2807-1 Decal, Oil Pressure/Head Temp.
24 6875 PTO Alignment Arrow
25 8746 Universal Joint Lube
26 2732 Decal (60")
Option Decals (applied only to units with corresponding Options installed)
27 5877 Lights, On-Off
NOTE: All parts requiring decals are shipped with decals applied.
Use only genuine Walker
58

TRACTOR AND DECK DECALS

Body, RH near Seat
Transfer Mount
Rear Body (one on each side)
Body, LH near Seat
Chassis
Body
Body
Carrier Frame
Deck Footrest, Front
Rear Body
Engine, LH Side
Rear Body, Underside
Air Cleaner Bracket
Deck Housing (one on each end)
Carrier Frame
Deck Housing
Carrier Frame
Deck Housing
Side Discharge Shield
Rear Body, RH Side
Rear Body, LH Side
Engine
Body
Universal Joint Tube Assembly
Mount Bracket / PTO Guard
Deck Housing, Front
Body
®
replacement parts.
LOCATION NO.
REQ'D SD
1
1
2
1
2
1
1
1
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
1
1
1
1
Effective Date 03-31-08
