  • Page 1 RX-22G & RX-24G LCD Monitor User Manual displays.agneovo.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information Federal Communications Commission (FCC) Notice (U.S. Only) ............4 W EEE ............................... 5 P recautions Notice ............................... 6 Cautions W hen Setting Up ........................6 Cautions W hen Using ..........................7 Cleaning and Maintenance ........................7 Notice for the LCD Display ........................
  • Page 3 TABLE OF CONTENTS 3 .7 Using Auto Adjustment Function ......................25 3 .8 Using ROTATE Function ........................25 3 .9 Lock i ng the OSD Menu ........................26 Ch ap ter 4: On Screen D isp lay M enu 4 .1 Using the OSD Menu ......................... 27 4 .2 OSD Menu Tree ..........................

  • Page 4: Safety Information

    SAFETY INFORMATION Safety Information Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Weee

    SAFETY INFORMATION WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.

  • Page 6: Precautions

    PRECAUTIONS P recautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symb ols used in th is manual This icon indicates the existence of a potential haz a rd that could result in personal injury or damage to the product. This icon indicates important operating and servicing information.

  • Page 7: Cautions W Hen Using

    PRECAUTIONS Cautions Wh en Using Use only the power cord supplied with the LCD display. The power outlet should be installed near the LCD Warning : display and be easily accessible. Unplug the power cord If an extension cord is used with the LCD display, from the power outlet and ensure that the total current consumption plugged refer to qualified service...

  • Page 8: Notice For The Lcd Display

    PRECAUTIONS Notice for th e L CD D isp lay In order to maintain the stable luminous performance, it is recommended to use low brightness setting. Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time.

  • Page 9: Ch Ap Ter 1 : P Roduct D Escrip Tion 1.1 Pack A Ge Contents

    Must use only the supplied power adapter: RX-22G & RX-24G ♦ ADAPTER TECH Quick Start Guide Model no.: ATS0 4 0 T-P120 RX-22G & RX-24G LCD Monitor Rating: 12V/3 .3 A RX-22G/RX-24G_Quick Guide_V010 displays.agneovo.com ♦ DELTA ELECTRONICS, INC. Model no.: ADP-4 0 DD B Rating: 12V/3 .3 3 A...

  • Page 10: W All Mounting Installation Preparation

    75mm other horiz o ntal surface overhead are strongly advised to contact AG Neovo for consultations and solutions to help ensure a most pleasurable and fulfilling display experience. Note: Tak e measures to prevent the...

  • Page 11: Removing The Base Stand

    PRODUCT DESCRIPTION 1 .2 .2 R emov ing th e B ase Stand ay the C display face down on a at even surface Note: Remove the screws* securing the base stand from the LCD (* ) The screw siz e is M4 x 10 mm. display.

  • Page 12: Lcd Display Overview

    PRODUCT DESCRIPTION 1 .3 L CD D isp lay Ov erv iew 1 .3 .1 Front V iew and K eyp ad B uttons A UT O Hot Key: Auto Adjustment/Rotate Hot Key: PIP/PBP Select • For VGA input signal source, press to •...

  • Page 13: Rear View

    PRODUCT DESCRIPTION 1 .3 .2 R ear V iew S-VIDEO COMPOSITE-1 COMPOSITE-2 AUDIO AUDIO USB (SERVICE) DC IN HDMI DisplayPort AUDIO IN RS232 D C IN COM P OSIT E- 1 / COM P OSIT E- 2 IN Connect with the supplied power adaptor. Connect Composite (CVBS) signals input.

  • Page 14: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS Ch ap ter 2 : M ak ing Connections 2 .1 Connecting th e P ow er Connect the power cord to the power adapter. Connect the power adapter to the DC power input at the rear of the LCD display. Connect the power cord plug to a power outlet or a power supply.

  • Page 15: Connecting Input Source Signals

    MAKING CONNECTIONS 2 .2 Connecting Inp ut Source Sig nals 2 .2 .1 Connecting a Comp uter Using V G A Cab les Connect one end of a VGA cable to the VGA connector of the LCD display and the other end to the VGA connector of the computer.

  • Page 16: Using Hdmi Cables

    MAKING CONNECTIONS Using H D M I Cab les Connect one end of an HDMI cable to the HDMI connector of the LCD display and the other end to the HDMI connector of the computer. HDMI Using D isp layP ort Cab les Connect one end of a DisplayPort cable to the DisplayPort connector of the LCD display and the other end to the DisplayPort connector of the computer.

  • Page 17: Using Rs23 2 Cables

    MAKING CONNECTIONS Using R S2 3 2 Cab les Connect one end of an RS23 2 cable to the RS23 2 connector of the LCD display and the other end to the RS23 2 connector of the computer. RS232 Using A udio Cab les Connect one end of an audio cable to the AUDIO IN connector at the rear of the LCD display and the other end to the audio out connector of the computer.

  • Page 18: Connecting A Video Device

    MAKING CONNECTIONS 2 .2 .2 Connecting a V ideo D ev ice Using Comp osite (CV B S) Cab les Connect one end of a Composite (CVBS) cable to the COMPOSITE 1 / COMPOSITE 2 IN connector of the LCD display and the other end to the Composite (CVBS) connectors of your device. For audio input, connect an RCA cable to the AUDIO IN connectors of the LCD display and the audio out connector of your device.

  • Page 19: Using S-Video Cables

    MAKING CONNECTIONS Using S- V ideo Cab les Connect one end of an S-Video cable to the S-VIDEO connector of the LCD display and the other end to the S-VIDEO connector of your device. For audio input, connect an RCA cable to the AUDIO IN connectors of the LCD display and the audio out connector of your device.

  • Page 20: Using Displayport Cables

    MAKING CONNECTIONS Using D isp layP ort Cab les Connect one end of a DisplayPort cable to the DisplayPort connector of the LCD display and the other end to the DisplayPort connector of your device. DisplayPort...

  • Page 21: Ch Ap Ter 3 : Using Th E L Cd D Isp Lay 3 .1 Turning On The Power

    CHAPTER 3: USING THE LCD DISPLAY Ch ap ter 3 : Using th e L CD D isp lay 3 .1 T urning on th e P ow er Note: ♦ The LCD display still consumes P OWER button power as long as the power L ED indicator cord is connected to the power outlet.

  • Page 22: Adjusting The Volume

    USING THE LCD DISPLAY 3 .3 A dj usting th e V olume Hot K ey: A udio V olume A dj ustment Press the button to call out the volume bar. Press the button to increase volume or the button to decrease volume.

  • Page 23: Using Picture-In-Picture (Pip)

    USING THE LCD DISPLAY 3 .5 Using P icture- in- P icture (P IP ) The Picture-in-Picture (PIP) and Picture-by-Picture (PIP) feature allows viewing of more than one input source signal on the LCD display. 3 .5.1 P IP / P B P Op tions Hot K ey: P IP / P B P Select Press the button repeatedly to enable and scroll among the PIP/PBP options.

  • Page 24: Pip/Pbp Swap

    USING THE LCD DISPLAY 3 .5.2 P IP / P B P Sw ap The main and the sub source signals set in PIP/PBP Setting can be easily swapped using the k e ypad. Note: ♦ Sub source PIP/PBP Swap can only be Main source executed if PIP is enabled, see page 3 9 .

  • Page 25: Using Auto Adjustment Function

    USING THE LCD DISPLAY 3 .7 Using A uto A dj ustment Function Note: ♦ Auto Adjustment function is available only during VGA input signals. ♦ Hot K ey: A uto A dj ustment/ R otate It is recommended to use the auto adjustment function when Auto Adjustment function automatically tunes the LCD display to its using the LCD display for the...

  • Page 26: Lock I Ng The Osd Menu

    USING THE LCD DISPLAY 3 .9 L ock ing th e OSD M enu Lock the OSD menu to protect the LCD display from unauthorised users or from accidentally pressing the k e ypad. To lock the OSD, press and hold the k e ypad buttons listed below for at least 5 seconds or until the O S D message appears.

  • Page 27: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU Ch ap ter 4: On Screen D isp lay M enu 4.1 Using th e OSD M enu Op eration Display the main menu screen. Press the button. 1 9 2 0 x 1 0 8 0 6 0 H z B R I G H T N E S S B R I G H T N E S S...
  • Page 28 ON SCREEN DISPLAY MENU Op eration Select the submenu item. Press the button. 0 x 1 0 8 0 6 0 H z B R I G H T N E S S R I G H T N E S S C O N T R A S T O L O U R T E M P .

  • Page 29: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD M enu T ree 1 9 2 0 x 1 0 8 0 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P .
  • Page 30 ON SCREEN DISPLAY MENU M ain M enu Sub menu R emark s • See page 3 5. • • T T • • C • • • • • • CLOCK • FULL See page 3 8 . • REAL •...
  • Page 31 ON SCREEN DISPLAY MENU M ain M enu Sub menu R emark s 10 . SY STEM 2 • See page 4 6 . • • MODE • DCR • • LOW POW ER • 11. ECOSMART SENSOR • ENABLE See page 4 8 .

  • Page 32: Chapter 5: Adjusting The Lcd Display

    CHAPTER 5: ADJUSTING THE LCD DISPLAY Ch ap ter 5: A dj usting th e L CD D isp lay 5.1 B rig h tness 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the B R I G H T N E S S OSD window.
  • Page 33 ADJUSTING THE LCD DISPLAY Orig inal Setting H ig h Setting L ow Setting BRIGHTNESS CONTRAST BLACK LEVEL...

  • Page 34: Colour Temp

    ADJUSTING THE LCD DISPLAY 5.2 Colour T emp . 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD N E U T R A L window. W A R M B R I G H T N E S S C O O L U S E R...

  • Page 35: Image Setting

    ADJUSTING THE LCD DISPLAY 5.3 Imag e Setting 1. Press the button to call out the OSD 1 9 2 0 x 1 0 8 0 6 0 H z S H A R P N E S S window. B R I G H T N E S S C O N T R A S T S A T U R A T I O N...
  • Page 36 ADJUSTING THE LCD DISPLAY Item Function Op eration R ang e Adjusts black and white levels for AUTO video. Press the button to FULL select the setting. Note: This menu option is only LIMITED available if the input source is HDMI. Signal source from PC - PC signal at a full range (Grayscale 0 -255) state: COLOUR RANGE Monitor OSD colour range: Full...
  • Page 37 ADJUSTING THE LCD DISPLAY Item Function Op eration R ang e elects a predefined picture mode setting. STANDARD Note: W hen the setting is set CCTV Press the button to PICTURE MODE to sR G B , the BRIGHTNESS, VIDEO select the setting.

  • Page 38: Aspect Ratio

    ADJUSTING THE LCD DISPLAY 5.4 A sp ect R atio 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD F U L L window. R E A L B R I G H T N E S S N A T I V E Z O O M...

  • Page 39: Pip Setting

    ADJUSTING THE LCD DISPLAY 5.5 P IP Setting 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD P I P O F F window. B R I G H T N E S S P I P P B P C O L O U R T E M P .
  • Page 40 ADJUSTING THE LCD DISPLAY Note: Any input signal may be set as the main or the sub source signal. However, some input signals are not supported to be paired together as the main and the sub source signals. Refer to the following table for compatibility options: M ain Source Inp ut Source V G A...

  • Page 41: Anti-Burn

    ADJUSTING THE LCD DISPLAY 5.6 A nti- B urn- in 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the E N A B L E O F F OSD window.

  • Page 42: Osd Setting

    ADJUSTING THE LCD DISPLAY 5.7 OSD Setting 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD T R A N S P A R E N C Y window.

  • Page 43: Audio Setting

    ADJUSTING THE LCD DISPLAY 5.8 A udio Setting 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD V O L U M E window. B R I G H T N E S S A U D I O C O L O U R T E M P .

  • Page 44: System 1

    ADJUSTING THE LCD DISPLAY 5.9 System 1 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD P O W E R S A V I N G window.
  • Page 45 Note: This menu option is only available if the input source is HDMI. Enables or disables the logo feature. If the setting is set to ON, the AG Neovo LOGO logo is brie y displayed after the display is powered on.

  • Page 46: System 2

    ADJUSTING THE LCD DISPLAY 5.1 0 System 2 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD S U P E R R E S O L U T I O N window.
  • Page 47 ADJUSTING THE LCD DISPLAY Item Function Op eration R ang e Activates DCR. This feature provides automatic adjustment of picture brightness and contrast at high speed and dynamic contrast range, such as when watching (Dynamic movies. DCR is suitable for indoor viewing. Contrast Ratio) Note: W hen the DCR function is activated, the BACK LIGHT and ECOSMART SENSOR...

  • Page 48: Ecosmart Sensor

    ADJUSTING THE LCD DISPLAY 5.1 1 EcoSmart Sensor W ith the built-in EcoSmart sensor, users can enable the Eco Smart feature to automatically adjust the LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise energy efficiency Note: Please mak e sure the EcoSmart sensor is not covered when enabling this function.
  • Page 49 ADJUSTING THE LCD DISPLAY Item Function Op eration V alue AUTO Press the button to Sets the auto brightness mode. USER select the setting. The mode can be set to: MODE • A UT O - This mode is the default mode. The LCD brightness automatically adjusts to the ambient brightness.

  • Page 50: Input Select

    ADJUSTING THE LCD DISPLAY 5.1 2 Inp ut Select 1 9 2 0 x 1 0 8 0 6 0 H z 1. Press the button to call out the OSD V G A window. D V I B R I G H T N E S S H D M I C O L O U R T E M P .

  • Page 51: Chapter 6: Appendix

    CHAPTER 6: APPENDIX Ch ap ter 6 : A p p endix 6 .1 Warning M essag es Warning M essag es Cause Solution The resolution or the refresh rate of • Change the resolution or the I N P U T S I G N A L the graphics card of the computer refresh rate of the graphics O U T O F R A N G E...

  • Page 52: Supported Resolutions

    APPENDIX 6 .2 Sup p orted R esolutions R esolution P C M ode R efresh R ate H oriz o ntal V ertical IBM VGA 7 20 4 0 0 IBM VGA 6 4 0 4 8 0 Apple Mac II 6 4 0 4 8 0 VESA...

  • Page 53: Troubleshooting

    APPENDIX R esolution V ideo M ode R efresh R ate H oriz o ntal V ertical HDTV 19 20 10 8 0 HDTV 19 20 10 8 0 HDTV 19 20 10 8 0 HDTV 19 20 10 8 0 6 .3 T roub lesh ooting P rob lem P ossib le Cause and Solution...
  • Page 54 APPENDIX P rob lem P ossib le Cause and Solution Cannot adjust the back l ight • The Eco Smart feature is enabled. Set the ECOSM A R T SENSOR > setting. ENA B L E setting to OFF to disable the Eco Smart feature (see page 4 8 ).

  • Page 55: Transporting The Lcd Display

    APPENDIX 6 .4 T ransp orting th e L CD D isp lay To transport the LCD display for repair or shipment, place the display in its original pack a ging carton. P lace th e tw o foam cush ions on each side of th e L CD disp lay for p rotection. P lace th e L CD disp lay dow n in th e b ox .
  • Page 56 APPENDIX R X - 2 4G...

  • Page 57: Isplay Pecifications

    CHAPTER 7: SPECIFICATIONS R X - 2 2 G R X - 2 4G Panel Panel Type LED-Back l it TFT LCD (TN Technology) LED-Back l it TFT LCD (TN Technology) Panel Siz e 21.5" 23 .6 " Max. Resolution FHD 19 20 x 10 8 0 FHD 19 20 x 10 8 0 Pixel Pitch...

  • Page 58: Display Dimensions

    (M4xL10) x8 137.4 137.4 277.4 277.4 Company Address: 5F-1, No. 3 -1, Park Street, Nangang District, Taipei, 1150 3 , Taiwan. Copyright © 20 20 AG Neovo. All rights reserved. RX 4 GA0 /RX 2G0 0 _ UM_ V0 13...
