Summary of Contents for AG Neovo RX-W32

  • Page 1 RX-W32 & RX-W42 LCD Display...
  • Page 2: Table Of Contents

    Table of Contents Preface FCC Declaimers ............................4 WEEE ................................5 Hg ..................................5 Precautions Notice ................................6 Cautions When Setting Up ..........................6 Cautions When Using ............................7 Cleaning and Maintenance ..........................7 Notice for the LCD Display ..........................8 Chapter 1: Product Description 1.1 Package Contents ...........................9 1.2 Wall Mounting Installation Preparation ....................10 1.2.2 Removing the Base Stand......................10...
  • Page 3 5.11 Input Select ............................44 Chapter 6: Appendix 6.1 Warning Messages ..........................45 6.2 Troubleshooting ............................46 6.3 Transporting the LCD Display .........................47 Chapter 7: Specifications 7.1 Display Specifications ..........................48 7.2 Display Dimensions ..........................49 7.2.1 RX-W32 Dimensions ........................49 7.2.2 RX-W42 Dimensions ........................49 Table of Contents...
  • Page 4: Fcc Declaimers

    Safety Information This FCC Class-B compliant digital device complies with the Interference- Causing Equipment Regulations of Canada. FCC Declaimers This device complies with Section 15 of the FCC listing. The operation procedures must meet the following conditions: (1) the device must not cause any damaging interference; and (2) this device must accept any received interference, including any unpredictable interference that may possibly occur.
  • Page 5: Weee

    WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.
  • Page 6: Precautions

    Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence of a potential hazard that could result in personal injury or damage to the product. This icon indicates important operating and servicing information. Notice •...
  • Page 7: Cautions When Using

    Cautions When Using Use only the power cord supplied with the LCD display. The power outlet should be installed near the LCD display and be easily accessible. If an extension cord is used with the LCD display, ensure that the total current consumption plugged into the power outlet does not exceed the ampere rating.
  • Page 8: Notice For The Lcd Display

    Notice for the LCD Display In order to maintain the stable luminous performance, it is recommended to use low brightness setting. Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time.
  • Page 9: Chapter 1: Product Description

    1. Product Description 1.1 Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. LCD display Power cord Remote control DVI-D cable VGA cable Audio cable User Manual Note: ♦...
  • Page 10: Wall Mounting Installation Preparation

    Removing the Handles ♦ Use only the 400 x 200 mm wall mount kit recommended Lay the LCD by AG Neovo. display face down ♦ Secure the LCD display on on a flat even a solid wall strong enough to surface.
  • Page 11: Lcd Display Overview

    1.3 LCD Display Overview 1.3.1 Front View and Keypad Buttons Keypad AUTO POWER Display screen The LCD display screen is protected by NeoV Optical Glass. LED indicator Green - Power on AUTO Amber - Standby mode POWER Off - Power off Remote control sensor (See page 14.) SOURCE...
  • Page 12: Rear View

    1.3.2 Rear View AC IN RS-232C COMPONENT DC OUT S-VIDEO CVBS AUDIO IN Max 350mA 100-240V 50-60Hz AUDIO IN VIDEO IN AUDIO IN VIDEO 2 VIDEO 1 AUDIO RS-232C COMPONENT S-VIDEO CVBS AC IN DC OUT AUDIO IN AUDIO IN VIDEO IN AUDIO IN VIDEO 2...
  • Page 13: Remote Control

    1.4 Remote Control 1.4.1 Remote Control Buttons Power Key Lock CVBS 1 YPbPr1 S-Video CVBS 2 YPbPr2 Volume Left Menu Right Down Mute POWER button Navigation button Press to turn the monitor on or off. Press navigate through the OSD menu and adjust the settings.
  • Page 14: Installing The Remote Control Batteries

    1.4.2 Installing the Remote Control Batteries Turn the remote control upside down. Press and hold the lock tab then pull the battery compartment out of the slot. Notes about the battery: ♦ Do not leave the remote control in an extremely hot or Place the battery on the humid place.
  • Page 15: Chapter 2: Making Connections

    2. Making Connections 2.1 Connecting the AC Power Connect the power cord to the AC power input at the rear of the LCD display. Connect the plug to a power outlet or a power supply. AC IN RS-232C COMPONENT DC OUT S-VIDEO CVBS AUDIO IN...
  • Page 16: Connecting Input Source Signals

    2.2 Connecting Input Source Signals 2.2.1 Connecting a Computer Using VGA Cables Connect one end of a D-sub cable to the VGA connector of the LCD display and the other end to the D-sub connector of the computer. RS-232C AC IN COMPONENT DC OUT S-VIDEO...
  • Page 17: Connecting An Audio Device

    Connecting an Audio Device Connect one end of an audio cable to the audio port at the rear of the LCD display and the other end to the audio out port of the computer. AC IN RS-232C COMPONENT DC OUT S-VIDEO CVBS AUDIO IN...
  • Page 18: Connecting A Camera Or Video Device

    2.2.2 Connecting a Camera or Video Device Using CVBS Cables Connect one end of a CVBS cable to the COMPOSITE connectors of the LCD display and the other end to the COMPOSITE connectors of your device. For audio input, connect an RCA cable to the audio in connector of the LCD display and the audio out connector of your device.
  • Page 19: Using S-Video Cables

    Using S-Video Cables Connect one end of an S-Video cable to the S-VIDEO connector of the LCD display and the other end to the S-VIDEO connector of your device. For audio input, connect an RCA cable to the audio in connector of the LCD display and the audio out connector of your device.
  • Page 20: Connecting Multiple Lcd Displays

    PC input signal. However, if the power cord of that LCD display is unplugged from the power outlet, all succeeding displays also lose the signal. ♦ To ensure compatibility, use only AG Neovo displays. Chapter 2: Making Connections...
  • Page 21: Chapter 3: Using The Lcd Display

    3. Using the LCD Display 3.1 Turning on the Power 3.1.1 Using the Keypad Plug the power cord to a power outlet or power supply. Press the POWER button on the keypad to turn the LCD display The LED indicator turns GREEN.
  • Page 22: Selecting The Input Source Signal

    3.2 Selecting the Input Source Signal 3.2.1 Using the Keypad Notes: SOURCE button ♦ After selecting an input Press the SOURCE button on the source signal, the input keypad. source signal message appears on the screen briefly. The input signal screen is displayed on screen.
  • Page 23: Adjusting The Volume

    3.3 Adjusting the Volume 3.3.1 Using the Keypad Press either to call out the volume bar. Press to increase volume. Press to decrease volume. VOLUME buttons AUTO POWER 3.1.2 Using the Remote Control Power Key Lock CVBS 1 YPbPr1 S-Video On the remote control, press increase volume.
  • Page 24: Locking The Osd Menu

    3.5 Locking the OSD Menu Lock the OSD menu to protect the LCD display from unauthorised users or from accidentally pressing the keypad or the remote control buttons. To lock the OSD, press and hold the keypad buttons listed below for at least 5 seconds or until the message appears.
  • Page 25: Using Picture-In-Picture (Pip)

    3.6 Using Picture-in-Picture (PIP) The Picture-in-Picture (PIP) feature allows viewing of more than one input source signal on the LCD display. 3.6.1 PIP Options On the keypad or the remote control, press repeatedly to enable and scroll among the PIP options. Options are as Info: follows: ♦...
  • Page 26: Chapter 4: On Screen Display Menu

    4. On Screen Display Menu 4.1 Using the OSD Menu Remote Control Keypad Display the main menu screen. Press Press Menu 1 2 8 0 x 1 0 2 4 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R...
  • Page 27 Remote Control Keypad Select the submenu item. Press Press Down 6 0 H z B R I G H T N E S S E S S C O N T R A S T S E T T I N G E T T I N G The highlighted item with an orange arrow indicates the active submenu.
  • Page 28: Osd Menu Tree

    4.2 OSD Menu Tree 1 2 8 0 x 1 0 2 4 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R S E T T I N G I M A G E...
  • Page 29 Main Menu Submenu Remarks 4. Aspect Ratio During Video input signal only: See page 36. • H. Zoom • V. Zoom • H. Position • V. Position 5. PIP Setting • See page 37. • Main Source • Sub Source •...
  • Page 30: Chapter 5: Adjusting The Lcd Display

    5. Adjusting the LCD Display 5.1 Brightness Setting 1 2 8 0 x 1 0 2 4 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R S E T T I N G...
  • Page 31: Colour Setting

    5.2 Colour Setting 1 2 8 0 x 1 0 2 4 6 0 H z C O L O U R T E M P . 6 5 0 0 K B R I G H T N E S S 5 4 0 0 K C O N T R A S T 9 3 0 0 K...
  • Page 32 Operation Value Remote Control Keypad 1 Press 1 Press to select USER. select USER. Down 2 Press 2 Press Right • User - This allows users to set the colour 3 Press 3 Press temperature by adjusting the R, G, B settings to select among R, select among R, G, Down...
  • Page 33: Image Setting (Vga Only)

    5.3 Image Setting (VGA only) Note: During DVI input source signal, Image Setting is disabled and grayed out. 1 2 8 0 x 1 0 2 4 6 0 H z S H A R P N E S S B R I G H T N E S S P H A S E C O L O U R...
  • Page 34: Image Setting (Video Signals)

    5.4 Image Setting (Video signals) 1 2 8 0 x 1 0 2 4 6 0 H z S H A R P N E S S B R I G H T N E S S C O N T R A S T S A T U R A T I O N C O L O U R S E T T I N G...
  • Page 35 Operation Range / Item Function Value Remote Control Keypad Allows you to select a video mode with Press Press preset image settings. Left Right • User - The default user setting. Video Mode • t - Suitable when viewing images with text. •...
  • Page 36: Aspect Ratio

    5.5 Aspect Ratio Note: Aspect Ratio is only available during video input signals. 1 2 8 0 x 1 0 2 4 6 0 H z A S P E C T R A T I O O V E R S C A N B R I G H T N E S S U N D E R S C A N N A T I V E...
  • Page 37: Pip Setting

    5.6 PIP Setting 1 2 8 0 x 1 0 2 4 6 0 H z P I P O F F P I P B R I G H T N E S S P A P P A P 4 : 3 M A I N S O U R C E...
  • Page 38 Operation Item Function Remote Control Keypad Allows you to select the sub source signal. VGA / DVI / CVBS1 / CVBS2 / S-VIDEO / YPbPr1 / YPbPr2 Note: Sub Source Press Press ♦ The selected main source cannot be Left Right selected as the sub source anymore.
  • Page 39: Anti-Burn-In

    5.7 Anti-Burn-In Anti-Burn-In is useful in preventing image retention on the LCD display. 1 2 8 0 x 1 0 2 4 6 0 H z E N A B L E O F F B R I G H T N E S S I N T E R V A L ( H O U R S ) C O L O U R...
  • Page 40: Osd Setting

    5.8 OSD Setting 1 2 8 0 x 1 0 2 4 6 0 H z T R A N S P A R E N C Y B R I G H T N E S S H . P O S I T I O N C O L O U R S E T T I N G V .
  • Page 41: Audio Setting

    5.9 Audio Setting 1 2 8 0 x 1 0 2 4 6 0 H z V O L U M E B R I G H T N E S S A U D I O O F F C O L O U R S E T T I N G I M A G E...
  • Page 42: Other Setting

    5.10 Other Setting 1 2 8 0 x 1 0 2 4 6 0 H z P O W E R S A V I N G O F F B R I G H T N E S S M O D E C O L O U R S E T T I N G...
  • Page 43 Operation Item Function Range Remote Control Keypad Enables or disables RS-232 connection. With RS-232 connection, RS-232C Press multiple displays can be Press Left Right connected together in a series to show the output of one computer. Sets the monitor ID of the LCD display.
  • Page 44: Input Select

    5.11 Input Select 1 2 8 0 x 1 0 2 4 6 0 H z V G A P R E S S B R I G H T N E S S D V I C O L O U R S E T T I N G P R E S S C V B S 1...
  • Page 45: Chapter 6: Appendix

    6. Appendix 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh • Change the resolution rate of the graphics card of or the refresh rate of the I N P U T S I G N A L O U T O F R A N G E the computer is set too high.
  • Page 46: Troubleshooting

    6.2 Troubleshooting Problem Possible Cause and Solution No picture. • Check if the LCD display is turned ON. • Check if the power cord is properly connected to the LCD • LED indicator is OFF. display. • Check if the power cord is plugged into the power outlet. •...
  • Page 47: Transporting The Lcd Display

    6.3 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. Attach the handles (if removed). Lay the LCD display face down on a flat even surface. Screw the handles to the LCD display. AC IN COMPONENT DC OUT...
  • Page 48: Chapter 7: Specifications

    7. Specifications 7.1 Display Specifications RX-W32 RX-W42 Panel Panel Size 32” 42” Max. Resolution WXGA 1366 x 768 Full HD 1920 x 1080 Frequency (H/V) H: 24 kHz - 82 kHz H: 24 kHz - 82 kHz V: 50 Hz - 85 Hz...
  • Page 49: Display Dimensions

    7.2 Display Dimensions 7.2.1 RX-W32 Dimensions 170mm 434mm 101mm 788mm 400mm 478mm 200mm AC IN RS-232C COMPONENT DC OUT S-VIDEO CVBS AUDIO IN Max 350mA 100-240V 50-60Hz AUDIO IN VIDEO IN AUDIO IN VIDEO 2 VIDEO 1 AUDIO AUTO POWER...
