- Page 1 BG96 Windows USB Driver Installation Guide LTE Module Series Rev. BG96_Windows_USB_Driver_Installation_Guide_V1.0 Date: 2017-06-30 www.quectel.com...
- Page 2 QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION.
-
Page 3: About The Document
LTE Module Series BG96 Windows USB Driver Installation Guide About the Document History Revision Date Author Description Hunter LV/ 2017-06-30 Initial Daisy TIAN BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 2 / 17... -
Page 4: Table Of Contents
LTE Module Series BG96 Windows USB Driver Installation Guide Contents About the Document ........................... 2 Contents ............................... 3 Figure Index ..............................4 Introduction ............................5 Installation of USB Driver........................6 2.1. Preparation ..........................6 2.2. Installation Procedures ......................7 2.3. - Page 5 LTE Module Series BG96 Windows USB Driver Installation Guide Figure Index FIGURE 1: “DEVICE MANAGER” INTERFACE OF WINDOWS SYSTEM WITHOUT QUECTEL DRIVERS ... 6 FIGURE 2: CONFIRM INSTALLATION ....................... 7 FIGURE 3: CHOOSE DESTINATION LOCATION ....................8 FIGURE 4: COPYING FILES ..........................8 FIGURE 5: AUTOMATIC INSTALLATION ......................
-
Page 6: Introduction
LTE Module Series BG96 Windows USB Driver Installation Guide Introduction This document illustrates how to install USB driver for Quectel BG96 module on Windows operating systems, with provided installation package. The installation package (Quectel_BG96_Windows_USB_Driver) supports Windows XP, Windows Vista, Windows 7 and Windows 8 operating systems. This document introduces the installation procedure on Windows 7 system as an example. -
Page 7: Installation Of Usb Driver
Before USB driver installation, please connect BG96 to PC via USB cable first and then press BG96’s power key to power up the module. If you have never installed any Quectel driver on your system before, there would be a prompt about new device which indicates you to update the drivers. Please ignore the prompt and go to the next step. -
Page 8: Installation Procedures
For Windows XP system, you MUST ensure the BG96 module has been connected to PC before installing the USB driver. 2.2. Installation Procedures Before USB driver installation, please get the latest installation package from Quectel. This document takes the installation of Quectel_BG96_Windows_USB_Driver_V1.0 as an example, and the details are shown as below. - Page 9 LTE Module Series BG96 Windows USB Driver Installation Guide Figure 3: Choose Destination Location 3. Prepare Driver Files Needed for Installation Click “Next” to go on, as shown below. Figure 4: Copying Files BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 8 / 17...
- Page 10 LTE Module Series BG96 Windows USB Driver Installation Guide 4. Automatic Installation It may take some time to install the driver, please wait patiently for the process to complete. Figure 5: Automatic Installation 5. Complete Installation The driver has been installed successfully, shown as below. Please click “Finish” to complete the installation.
- Page 11 LTE Module Series BG96 Windows USB Driver Installation Guide Figure 6: Complete Installation BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 10 / 17...
-
Page 12: Test
LTE Module Series BG96 Windows USB Driver Installation Guide After successful installation, customers can check the installation result through “Computer Management” “Device Manager”. Figure 7: Check USB Driver Installation Result for BG96 2.3. Test After the USB driver has been installed, customers can test whether the driver can work normally or not by QNavigator. - Page 13 LTE Module Series BG96 Windows USB Driver Installation Guide Figure 8: BG96 Testing via Navigator BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 12 / 17...
-
Page 14: Uninstallation Of Usb Driver
LTE Module Series BG96 Windows USB Driver Installation Guide Uninstallation of USB Driver This chapter mainly provides the way to uninstall USB driver for BG96. The uninstallation can be realized by re-operating installation package or adding/deleting program on “Control Panel”. By taking as an example, this document introduces using the latter method to uninstall the USB driver for BG96. - Page 15 LTE Module Series BG96 Windows USB Driver Installation Guide Figure 10: Uninstall the USB Driver 2. Check Uninstallation Setting Figure 11: Check Uninstallation Setting BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 14 / 17...
- Page 16 LTE Module Series BG96 Windows USB Driver Installation Guide 3. Confirm Uninstallation Click “Yes” to confirm the uninstallation. Figure 12: Confirm Uninstallation 4. Automatic Uninstallation It may take some time to uninstall, please wait patiently for the process to complete.
- Page 17 LTE Module Series BG96 Windows USB Driver Installation Guide 5. Complete Uninstallation The drivers have been uninstalled completely, as shown below. Click “Finish” to complete uninstallation. Figure 15: Complete Uninstallation 6. Check Uninstallation Result After the USB driver has been uninstalled successfully, the device will switch to uninstalled status.
- Page 18 LTE Module Series BG96 Windows USB Driver Installation Guide Figure 16: Check Uninstallation Result for BG96 USB Driver BG96_Windows_USB_Driver_Installation_Guide Confidential / Released 17 / 17...
