Velp Scientifica Chemglass CG-1997-V10 Instruction Manual

Digital heating magnetic stirrer

Advertisement

Quick Links

by VELP Scientifica
Instruction Manual
CG-1997-V10
CG-1997-V10E
Digital Heating Magnetic Stirrer
General Information
Before using the unit, please read the following instruction manual carefully.
Avant d'utiliser l'instrument, il est recommandé de lire attentivement le présent manuel d'instructions.
Caution, hot surface!
Attention, surface chaude!
Do not dispose of this equipment as urban waste, in accordance with EEC directive 2002/96/CE.
Ne pas recycler l'appareil comme déchet solide urbain, conformément à la Directive 2002/96/CE.
The product can be used with flammable liquids /
This unit must be used for laboratory applications indoor only. The manufacturer declines all responsibility for any use
of the unit that does not comply with these instructions. If the product is used in a not specified way by the manufacturer or
with non specified accessories, product's safety may be compromised.
Cet instrument ne peut être
toute responsabilité en cas d'utilisation non conforme aux instructions concernant ces instruments. Si le produit est utilisé
d'une manière non spécifiée par le fabricant ou accessoires non spécifiés, la sécurité du produit peut être compromise.
This unit has been designed and manufactured in compliance with the following standards:
L'instrument a été conçu et fabriqué conformément aux normes suivantes:
Safety requirements for electrical equipment for measurement, control and for laboratory use
Règles de sécurité pour appareils électriques de mesurage, de régulation et de laboratoire
Electrical equipment for laboratory use
General requirement - Canadian electrical code
VELP reserves the right to modify the characteristics of its products with the aim to constantly improving their quality.
Dans le but d'améliorer constamment la qualité de ses produits, VELP se réserve le droit d'apporter des modifications aux
caractéristiques de ceux-ci.
Safety Regulations / Consignes de Securité
The plug disconnects the instrument. Therefore, place the instrument where it can be quickly disconnected.
Le bouchon est le moyen de déconnexion de l'appareil. Par conséquent, placer l'appareil où il peut être rapidement
débranché.
Hotplate temperature: up to 370 °C / Température de la plaque chauffante: jusqu'à 370 °C.
The heated solution may release toxic, dangerous or poisonous gases. Adequate safety measures must be taken, in
accordance with the safety regulations in force, including the presence of hood and personal protective equipment (masks,
gloves, goggles, etc.).
La solution chauffée peut libérer gaz toxiques ou dangereux. Des mesures de sécurité adéquates doivent être prises, en
conformité avec les règlements de sécurité en vigueur, compris la présence de la hotte de laboratoire et équipements de
protection individuelle (masques, gants, lunettes, etc.).
www.cglifesciences.com
Phone: 1-800-843-1794
utilisé pour les applications de laboratoire à l'intérieur
Le produit peut être utilisé avec des liquides inflammables
1
seulement. Le fabriquant décline
IEC/EN 61010-1
IEC/EN 61010-2-051
UL 61010-1
CAN/CSA-C22.2 No.61010-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chemglass CG-1997-V10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Velp Scientifica Chemglass CG-1997-V10

  • Page 1 Phone: 1-800-843-1794 by VELP Scientifica Instruction Manual CG-1997-V10 CG-1997-V10E Digital Heating Magnetic Stirrer General Information Before using the unit, please read the following instruction manual carefully. Avant d’utiliser l’instrument, il est recommandé de lire attentivement le présent manuel d’instructions.
  • Page 2: Table Of Contents

    Beware of the effect of the magnetic field on cardiac pacemakers and data media. Veuillez tenir compte de l'influence du champ magnétique sur les stimulateurs cardiaques ou les supports de données. Position the instrument on a flat surface, with a distance from the wall of 30 cm (at least). Positionner l'appareil sur une surface plat, avec une distance de la paroi de 30 cm (au moins).
  • Page 3: Introduction

    1. Introduction The AREX-6 Digital PRO heating magnetic stirrer is used in the laboratory for general use and for all those applications that require a precise regulation for stirring speed and heating liquids. Aluminum alloy plate with ceramic coating Probe led Main switch Heating ON led Speed control knob...
  • Page 4: Operating Controls

    3. Operating controls ➢ Switch on the instrument through the main switch (2) ➢ Display shows software version, the last set point values and OFF on both displays (if “Start mode” is Commissioning set on Stop, see chapter 5) ➢ Adjust motor speed set point by turning the speed control knob (3) ➢...
  • Page 5: Setting Mode

    5. Setting mode Press both knobs for 3 seconds to enter into the setting mode when heating and stirring are off. Clicking the Timer/autoreverse button (F) it is possible to pass from one of the following parameter to the next ones: Parameter shown Default Range...
  • Page 6: Error Messages

    6. Error messages When the display shows an error message, the stirring and heating functions stop automatically. To remove the error message, disconnect the instrument from the power supply. Error code Cause Overtemperature (T > 430 °C) Excessive heating time The stirring system doesn’t run correctly Overtemperature of the external probe (T >...
  • Page 7: Accessories

    - use of the instrument that does not comply to the instructions/recommendations given in the present operating manual - use of non-original spare parts. 11. Declaration of conformity We, the manufacturer VELP Scientifica, under our responsibility declare that the product is manufactured in conformity with the following standards: EN 61010-1 (2001)
