LOCATION OF CONTROLS
1. Dir UP / ASP button
2. EQ button
3. MODE / PROG button
4. SKIP / SEARCH DN button
5. STOP button
6. PLAY / PAUSE button
7. SKIP / SEARCH UP button
PREPARATION BEFORE USING
Battery Installation
1. Open Battery Compartment cover.
2. Insert 2 batteries ( UM-3, "AA", LR6 or equivalent ) in the correct polarity as indicated.
(Heavy duty batteries are recommended).
3. Close the cover properly.
*In order to operate the player on batteries, the optional AC/DC adaptor must be
disconnected from the DC 4.5V Jack.
AC—DC Adaptor
*Before connection, make sure the AC voltage of the adaptor correspond to your local AC
outlet voltage.
CD9170 / English manual
8. LCD display
9. Battery compartment
10. Open knob
11. Volume knob
12. Phone jack
13. DC jack
ENG 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CD9170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOUNDMASTER CD9170

Summary of Contents for SOUNDMASTER CD9170

  • Page 1 CD9170 / English manual LOCATION OF CONTROLS 1. Dir UP / ASP button 8. LCD display 2. EQ button 9. Battery compartment 3. MODE / PROG button 10. Open knob 4. SKIP / SEARCH DN button 11. Volume knob 5. STOP button 12.

  • Page 2: Disc Playing

    CD9170 / English manual 1. Plug the DC output of the adaptor to the DC 4.5V jack. 2. Connect the adaptor (4.5V/600mA with polarity ) to a power outlet. DISC PLAYING Sound Effects During playback you can choose between the following Sound Effects:” BBS, Pop, Jazz, Rock, and Classic”, by pressing EQ BUTTON repeatedly.
  • Page 3 CD9170 / English manual Various Playing Modes MODE BUTTON — There are 3 kinds of function: ( FOR CD ) : A. Repeat Play During Play Mode · Press the MODE BUTTON once to play current track repeatedly. · The repeat indicator will appear in the display.
  • Page 4 CD9170 / English manual MODE BUTTON — There are 3 kinds of function: ( FOR MP3 DISC ) : A. Repeat Play During Play Mode · Press the MODE BUTTON once to play current track repeatedly. · The repeat indicator will appear in the display.
  • Page 5 CD9170 / English manual Program Play ( FOR CD ) 1. In stop mode, press the PROG BUTTON to make program memory. 2. “ ” will be displayed, “ 00” means track number to memory and “01” means program number.

  • Page 6: Low Battery Alert

    CD9170 / English manual LOW BATTERY ALERT When the low battery indicator appears on the display, please prepare to replace the new batteries. SPECIFICATIONS ≥ 15 mW ( 32 Ω ) Output Power Freq. Response 100 ~ 20000 Hz Power Source 2×UM-3”AA”...
