Table of Contents DECK POST INSTALLATION ..........5 PARTS FOR POST ASSEMBLY ........5 TILT MOUNTS ..............6 POST TO PLATE ASSEMBLY ........... 7 PLATE POSITION AND ANCHORING ....... 9 POST TILT MOUNT ASSEMBLY ........13 PARTS FOR POST TILT MOUNT ........15 TILT MOUNTS ..............
Parts for Post Assembly: back front this item is found in parts box Gather the following: 1. 1- Post 2. 1- Base Plate 3. 1 - Post Lock - Handle Not Included: Anchoring hardwear for Base Plate nXG 5550 anual...
Assembly Manual- Deck Post Tilt Mounts: The tilt mount portion of the deck post is provided in a separate box labeled “PTM” and is size specific. See below for the appropriate sizes. 55” Class Televisions Tools Required for Post Assembly: 9/16”...
Post to Plate Assembly: Upper Cable Entry Hole Lower Cable Exit Hole Hole Post Lock - Handle Located on side Set Screw Preinstalled Bottom of Post Brass Fitting for Friction Reduction nXG 5550 anual...
Page 8
Assembly Manual- Deck Post Slide bottom of post over the sleeve that is found towards the back of the mounting plate. Locate the post lock handle hole on the side of the post. Thread the handle into the hole. Do not tighten completely until post is in the preferred viewing position.
Plate Position and Anchoring your Deck Post: Base Plate with post Position the base plate with post in the spot where it is going to be mounted. Using the four holes indicated with the red ciricles, drill the holes for the hardwear you purchased to secure the base plate to the deck or patio.
Page 10
You have now completed the assembly portion of your Deck Post Mount. You have now completed the assembly portion of your Deck Post Mount.
Parts for Tilt Mount Assembly: these items are found in parts box 1. Previously assembled post: Deck Post, In-ground Post, or Portable Cart 2. 2- U-Bolts - (4) Flat Washers, (4) Lock Washers, (4) Powder Coated Nuts 3. 2- U-Bolt Saddles 4.
Assembly Manual- Post Tilt Mount Tilt Mounts: The tilt mount portion of the deck post is provided in a separate box labeled “PTM” and is size specific. PTM Boxes will contain the following items: 2- Mounting Arms 1- Locking Bar 1- Mounting Plate Tools Required for PTM Assembly: 9/16”...
U-Bolts and Mounting Plate Assembly: U-Bolt Post Saddle Top View U-Bolts should be hooked around the post and through the holes on the U-Bolt Saddles. These should be positioned near the upper cable entry hole. With U-Bolts and saddles in place, slide mounting plate over the U-bolt ends.
Page 18
Assembly Manual- Post Tilt Mount U-Bolts and Mounting Plate Assembly Cont.: 1. With U-bolts threaded through the mounting plates, place stainless steel flat washers over the bolt ends. 2. Place stainless steel lock washers over bolt ends. 3. Thread black powder coated nuts over bolt ends and hand tighten. See figure 3a for suggested mounting plate placement.
Page 20
Assembly Manual- Post Tilt Mount Warning: Do not plug speaker bar into A/C outlet until connections to the tele- vision have been plugged in. This will severely damage the speaker bar if not followed completely. Lay blanket down on flat sturdy surface.
Page 21
The following instructions apply to NXG 55” Television These will be in a separate Gather the clamping nuts with springs. bag shipped with the User Manual Packet. Remove the hex head screws and washers. Set the screws and washers in a secure location.
Page 22
With the help from a friend, lift the television and attach the hooks on the mounting arms to the plate on the tilt mount. Tighten knobs on arms once the tilt is set correctly for the television. Once the television is hung on the plate. Be sure to tighten the position set screw on the bottom of the mounting arm to secure the television in place.
