Step 1: Physical installation
1
•
Remove the green connector from the Output module.
2
•
Connect the appliance or breaker you want to control to the green connector by mounting
wires * using the removable push in spring connection.
3
•
Place the green connector back in the Output module.
•
Connect the Output module between to the Power Box, Genius or other modules via the B-
4
bus, using both B ports. Use the supplied Smappee Bus cable or a custom twisted-pair RJ10
cable.
* Use a solid cable with diameter range 0.5 to 1.5 mm² (20 AWG - 15 AWG) to connect the
output relay with the green connector. Stranded cable is not recommended. Strip the
wire for 5 mm.
Removable push in spring connection:
•
Press the orange push button above each wire input using a small flat screwdriver.
Keep the button pressed when inserting the wire. Release the orange push button
to hold the wire in place.
•
Make sure the wire is connected correctly. Pull gently on the wire and check
whether it's connected firmly.
You can use a custom RJ10 cable instead of the standard Smappee Bus cable. The RJ10
must be a twisted pair cable. Pins 1 & 4 and Pins 2 & 3 must be twisted pairs. See the
Smappee Bus cable specification in section 13 of the Infinity Installation manual.
Both ports (RJ10 connectors) of the modules are identical. There's no special attention
needed for making the interconnections.
Make sure the wire connection of the green connector is connected correctly. Pull gently
on the wire and check whether it's connected firmly.
Step 2: Configuration
The Output module can be configured when the Smappee Infinity is installed and operational. The
outputs can be configured separately (output 1 and output 2) or combined (output 1 & 2).
Configure the Output module using the Smappee App: Go to Control – All – Smart devices
– Add a smart device – Select Smappee Output Module. Proceed in the Smappee Energy
Monitor mobile app and follow the steps as shown.
If a physically installed Output module is not shown in the Output modules list in the
Smappee App, tap Scan for modules.
If you configure the outputs separately, redo these steps. Control – All – Smart devices –
Add a smart device – select Smappee Output Module.
