Golvo 8000/8008
Golvo is a versatile mobile lift, intended for use
lifting situations, for example, between bed and wheelchair,
to/from toilet, bath and shower, to/from the floor, for weighing
purposes and for lifting with a stretcher. Due to its foldable
arm rests, Golvo can to advantage be used for gait training.
The wireless hand control gives the caregiver the freedom
to work closer to the patient, which provides extra security
in the lifting situation. For the caregiver this also enables an
ergonomically enhanced work posture.
Golvo is equipped with the Liko Diagnostic System™, a
monitoring system which continually registers operating data
and automatically indicates when the lift is in need of service.
is a warning triangle used for situations which require extra care and attention.
In this document, the person being lifted is referred to as the patient, and the person helping is referred to
as the caregiver.
IMPORTANT!
Read the instruction guides for both the patient lift and lifting accessories before use. Lifting and transferring
a person always involves a certain level of risk. It is important to completely understand the contents of the
instruction guides. The equipment should only be used by trained personnel. Please contact your Liko/Hill-
Rom representative in the event of any uncertainties or questions.
Golvo 8008 LowBase™
Product Description
in most
The battery of the lift has built-in charge indicator where
the charging status of the battery can be read, even
when the battery is not attached to the lift. The battery is
of environmentally friendly NiMH type.
Golvo LowBase™, with its extra low base, height
clearance of 58 to 110 mm (2.28 to 4.33 inch.), is
suitable for lifting to and from beds/gurneys.
Individual fitting of the sling and other lifting accessories
is of utmost importance for function and safety when
using the lift.
Golvo™
Instruction Guide
7EN140105-02
2011-03-30
Applies to the following models:
Golvo 8000
Prod. No. 2000014
Golvo 8008
Prod. No. 2000015
Golvo 8008 LowBase™
Prod. No. 2000019
English
Advertisement
Table of Contents
Related Manuals for Hill-Rom Liko Golvo 8000
Summary of Contents for Hill-Rom Liko Golvo 8000
- Page 1 Golvo™ Instruction Guide English 7EN140105-02 2011-03-30 Applies to the following models: Golvo 8000 Prod. No. 2000014 Golvo 8008 Prod. No. 2000015 Golvo 8008 LowBase™ Prod. No. 2000019 Golvo 8000/8008 Golvo 8008 LowBase™ Product Description Golvo is a versatile mobile lift, intended for use in most The battery of the lift has built-in charge indicator where lifting situations, for example, between bed and wheelchair, the charging status of the battery can be read, even...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions ..................2 Definitions ....................... 3 Technical Data ....................3 Dimensions ..................... 4 Assembly ......................5 Disassembly ....................7 Operation ......................8 HandControl IR ..................... 10 Operation Panel.................... 10 Charging the Batteries .................. 11 Maximum Load ..................... 12 Recommended Lifting Accessories .............. -
Page 3: Definitions
Definitions Golvo 8000/8008 1. Lift Strap 2. Sling bar with latches 3. HandControl IR 4. Parking panel for sling bar 5. Holder for Quick Reference Guide and colour code for sling sizes 6. Product decal 7. Lift mast with inbuilt motor 8. -
Page 4: Dimensions
Dimensions Lateral view Top view L max L min Golvo LowBase F1 F Maximum reach Table of measurements (mm) Model L max L min max. min. max. min. max. min. Golvo 1995 1360 1115 800 1735 8000 Golvo 2090 1455 1185 870 1020 735 1100 1860... -
Page 5: Assembly
Assembly Before assembly, make sure you have the following parts and tools: • lift mast with control box and sling bar with latches, • bag containing: instruction guide, quick reference 2 M6 screws, bolt and lock nut (M8) guide, handle reinforcement for emergency lowering, charger cable, charger connector cable, •... - Page 6 7. Thread the cables through the 5. Assemble the sling bar (or other 6. Connect the cables as follows: opening in the cable lid. Push lifting accessory) with the provided - Charger cable to socket 1 the lid up and secure with the bolt and lock nut (M8).
-
Page 7: Disassembly
14. Place the charger cable on the intended hook 15. Activate the IR system by pressing any button on the operation panel. on the lift mast after completed charging. After assembly, make sure that: • the motion of the lift arm corresponds to the •... -
Page 8: Operation
Operation Activate: Reset: Emergency stop Electrical emergency lowering/raising Activate: Press the red button on the control box. The lift arm is lowered/raised electrically by Reset: Turn the button in the direction indicated pressing one of the markings for “down” and “up”, by the arrows. - Page 9 After mechanical emergency lowering / Restoring Adjustment of the lift interval level the lifting level If it is necessary to reach a lower level with the sling If the lift strap has been lengthened due to using the bar, this can be arranged by lengthening the lift strap emergency lowing function, the lift interval height will using the mechanical emergency lowering device.
-
Page 10: Handcontrol Ir
System™ indicates that the expected life time for the lift Up (lower speed) is approaching its end. Down (lower speed) Contact the service technician authorized by Liko/Hill-Rom. If the ELT proceeds to shine continuously when lifting, the lift Base widening should be taken out of service. -
Page 11: Charging The Batteries
Communication Mode (This lift is delivered in unique communication mode.) The lift has two different communication modes: Unique Communication Mode: The lift will only be controlled by the HandControl IR (one or more), which is enabled for IR control of the lift. Open Communication Mode: More than one lift can be controlled from one (or several) HandControl IR. Important! If more than one IR-controlled lift is used in the same room, each lift must be set to the unique communication mode in order to avoid several lifts from being affected simultaneously by one HandControl IR only. -
Page 12: Maximum Load
300 kg (660 lbs). In this case, the maximum load of 200 kg (440 lbs) applies to the assembled lift unit. Study the markings on the lift and lifting accessory, contact your Liko/Hill-Rom representative if you have any questions. - Page 13 3156021 and 3156018) and Universal TwinBar 670 (prod. no. 3156077). See the “Guide to Liko’s Quick-Release Hook System”, which can be Quick-release Hook Quick-release Hook downloaded from our website www.liko.com, or contact your Liko/Hill-Rom Universal representative for more information on the advantages of the Prod. No. 3156508 Prod.
- Page 14 Leg Protector set Golvo Grey, pair, fits: Golvo 7000, 8000 Prod. No. 2006011G Grey, pair, fits: Golvo 7007, 8008 Prod. No. 2006012G Cord for HandControl IR Prod. No. 2006030 Wall-mounted Battery Charger Prod. No. 2004108 Extra battery Prod. No. 2006107 w w w . l i k o . com Golvo •...
-
Page 15: Simple Troubleshooting
4. Make sure that the cables to the control box are connected correctly. 5. Check that the battery’s contact plates are not defective or broken. 6. If the problem remains, please contact Liko/Hill-Rom. The charger doesn’t work. 1. Make sure that the emergency stop has not been activated. -
Page 16: Inspection And Maintenance
For instructions on how to recycle your Liko product, please visit our website: www.liko.com. Product Changes Liko’s products undergo continuous development, which is why we reserve the right to make product changes without prior notice. Contact your Liko/Hill-Rom representative for advice and information about product upgrades. Design and Quality by Liko in Sweden Liko is quality certified in accordance with ISO 9001 and its equivalent for the medical device industry, ISO 13485.
