FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious injury,
death, or property damage.
—
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
—
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Leave the premises.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
—
Installation and service must be
performed by a qualified installer, service agency
or the gas supplier.
WARNING: If the information in these instructions are not followed exactly, a fire or
Installer: Please complete the details on the back cover and leave this manual with the
PFS report#:F18-431
Homeowner: Please keep these instructions for future reference.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180-CL2714.SP v1.00
CLARITY CL2714.SP
DIRECT VENT GAS FIREPLACE INSERT
with 7 Day Shutoff Standing Pilot (SP)
For use with natural gas (NG) or propane (LPG)
OPERATION & INSTALLATION MANUAL
explosion may result causing property damage, personal injury or loss of life.
homeowner.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes.
This appliance may be installed in an OEM Installation in a
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the Manufactured Home Construction and Safety
Standard, Tittle 24 CRF, Part 3280, in the United States, or the
Standard for Installation in Mobile Homes, CAN/CSA Z240 MH
Series, in Canada.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
A safety screen designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance and
shall be installed for the protection of children and other
at-risk individuals. If the safety screen becomes damaged,
the safety screen shall be replaced with the manufacturer's
safety screen for this appliance.
Date Installed:
Serial No.:
July 30, 2020
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blaze King CLARITY CL2714.SP
Summary of Contents for Blaze King CLARITY CL2714.SP
- Page 1 CLARITY CL2714.SP DIRECT VENT GAS FIREPLACE INSERT Date Installed: with 7 Day Shutoff Standing Pilot (SP) For use with natural gas (NG) or propane (LPG) Serial No.: OPERATION & INSTALLATION MANUAL FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Clarity CL2714 SP Page 2 SAFETY PRECAUTIONS _________________________________________________________________ 4 GENERAL ..................................4 YOUR SAFETY ................................4 INSTALLATION ................................5 GENERAL INFORMATION ________________________________________________________________ 6 APPLIANCE CERTIFICATION ..........................6 INSTALLATION CODES ............................6 SPECIFICATIONS..............................6 HIGH ALTITUDE INSTALLATION ........................6 CERTIFICATION LABEL __________________________________________________________________ 7 MA Code - CO Detector __________________________________________________________________ 8 DIMENSIONS _____________________________________________________________________________ 9... - Page 3 State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov Manufactured By Valley Comfort Systems Inc. Blaze King Industries 1290 Commercial Way 146 A Street Penticton, BC V2A 3H5 Walla Walla, WA 99362 CANADA U.S.A.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Clarity CL2714 SP Page 4 NOTE: Failure to follow these instructions could cause a malfunction of the fireplace, which could result in death, serious bodily injury, and/or property damage. GENERAL • Installation and repair should be done by a qualified service person. The appliance should be inspected before the first use and, at least, annually by a qualified service person. -
Page 5: Installation
Clarity CL2714 SP SAFETY PRECAUTIONS Page 5 INSTALLATION • Installation and service must be performed by a qualified installer, service agency or gas supplier • Only doors certified with the appliance shall be used. (see door part numbers in “PARTS LIST”) •... -
Page 6: General Information
GENERAL INFORMATION Clarity CL2714 SP Page 6 APPLIANCE CERTIFICATION This appliance is tested and certified to the following US and Canadian gas appliance standards: • ANSI Z21.88-2017 / CSA 2.33-2017 Vented Gas Fireplace Heaters, • CAN/CGA-2.17-M91 (R2014) Gas-Fired Appliance for Use at High Altitudes •... -
Page 7: Certification Label
Clarity CL2714 SP CERTIFICATION LABEL Page 7 180-CL2714.SP v1.00 July 30, 2020... -
Page 8: Ma Code - Co Detector
Clarity CL2714 SP MA Code - CO Detector Page 8 (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 9: Dimensions
Clarity CL2714 SP DIMENSIONS Page 9 RATING LABEL LOCATION The rating label is located below the firebox behind a flip down door. It is affixed to rectangular metal sheets that are chained to the appliance. " 35" " SECONDARY TRIM SAFETY SCREEN TRIM "... -
Page 10: Shroud And Shelf Options
SHROUD AND SHELF OPTIONS Clarity CL2714 SP Page 10 " S.Z4981 CL2714 SHROUD 24.5” x 36.5” " 38" S.Z4982 CL2714 SHROUD 26.5” X 38” " 40" S.Z4983 CL2714 SHROUD 29” x 40” 29" 44" S.Z4984 CL2714 SHROUD 32” x 44” 32"... - Page 11 Clarity CL2714 SP SHROUD AND SHELF OPTIONS Page 11 44" S.Z4985 CL2714 SHROUD 32” x 44” TRIMMABLE 32" S.Z4990 CL2714 45” SHELF W/ RISERS REQUIRES CL2714 SHROUD " 45" S.Z4994 CL2714 ANGLED SHROUD BASE REQUIRES S.Z4981 CL2714 SHROUD 24.5”x36.5” ” OR S.Z4982 CL2714 SHROUD 26.5”x38 "...
-
Page 12: Lighting Instructions
LIGHTING INSTRUCTIONS Clarity CL2714 SP Page 12 FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which is lit with a push button piezo lighter. When lighting the pilot, follow these instructions exactly. -
Page 13: 820 Nova Valve
Clarity CL2714 SP 820 NOVA VALVE Page 13 15 6 820 NOVA VALVE ON/PILOT/OFF Knob Manual HI-LO adjustment or pressure regulator adjustment Pilot adjustment Thermocouple connection Mounting for piezo & bracket Inlet pressure test point Outlet pressure test point Main operator Pilot outlet Main gas outlet Flange mounting screw holes... -
Page 14: Operating Instructions
Clarity CL2714 SP OPERATING INSTRUCTIONS Page 14 PILOT LIGHT Refer to the lighting instruction label on how to light the pilot. Check that the pilot has fully engulfed the thermocouple assembly (Fig.1). LIGHTING THE BURNER Standing Pilot (SP) The CLARITY CL2714 SP controls are located behind the hinged flap beneath the firebox.(Fig.2) To light the burner follow the steps below:... -
Page 15: Maintenance And Service
Clarity CL2714 SP MAINTENANCE and SERVICE Page 15 ROUTINE MAINTENANCE Regularly: • Clean and remove any lint accumulations or debris from the grills and combustion or convection air passage ways. • Keep the appliance area free from combustible materials, such as paper, wood, clothing, gasoline, flammable solids, liquids and vapors. -
Page 16: Safety Screen Trim Removal
MAINTENANCE and SERVICE Clarity CL2714 SP Page 16 SAFETY SCREEN TRIM REMOVAL 1. Turn off the appliance and allow it to cool down completely. 2. The safety screen trim fits into tabs on the appliance. Lift the safety screen trim up and out, away from the appliance, and set it aside. -
Page 17: Glass Door Replacement
The glass door must be purchased from a Blaze King dealer. No substitute materials are allowed. BURNER REMOVAL 1. Turn off the appliance and allow it to Fig.4... -
Page 18: Safety Screen Replacement
MAINTENANCE and SERVICE Clarity CL2714 SP Page 18 SAFETY SCREEN REPLACEMENT The CL2714 is supplied with a safety screen pre-installed inside the safety screen trim. If the safety screen becomes damaged it must be replaced with part #645-16305 for Z4921 Safety Screen Trim. -
Page 19: Fuel Conversion
Clarity CL2714 SP MAINTENANCE and SERVICE Page 19 FUEL CONVERSION THIS CONVERSION KIT SHALL BE INSTALLED BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS AND ALL APPLICABLE CODES AND REQUIREMENTS OF THE AUTHORITIES HAVING JURISDICTION. IF THE INFORMATION IN THESE INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A FIRE, EXPLOSION OR PRODUCTION OF CARBON MONOXIDE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. - Page 20 MAINTENANCE and SERVICE Clarity CL2714 SP Page 20 installationi i n n s s t t r r u u c c t t i i o o n n s s 820 NOVA HI/LO Conversion Kit WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer.
-
Page 21: Installation Planning
Clarity CL2714 SP INSTALLATION PLANNING Page 21 THIS FIREPLACE INSERT SHALL BE INSTALLED BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS AND ALL APPLICABLE CODES AND REQUIREMENTS OF THE AUTHORITIES HAVING JURISDICTION. This section of the owner’s manual is for the use of qualified service technicians only. Gas connections, clearances to combustibles, minimum fireplace dimensions, electrical systems, initial setup, and venting will be covered. -
Page 22: Factory Built Fireplace Or Zero Clearance Fireplace
INSTALLATION PLANNING Clarity CL2714 SP Page 22 The included label plate, shown below, must be permanently attached inside the cavity of the fireplace in a visible location. WARNING: This fi replace has been converted for use with a gas fi replace insert only and cannot be used for burning wood or solid fuels unless all original parts have been replaced, and the fi replace reapproved by the authority having jurisdiction. -
Page 23: Installation Clearances
Clarity CL2714 SP INSTALLATION CLEARANCES Page 23 OPERATION OF THIS HEATER WHEN NOT CONNECTED TO A PROPERLY INSTALLED AND MAINTAINED VENTING SYSTEM CAN RESULT IN CARBON MONOXIDE (CO) POISONING AND POSSIBLE DEATH MINIMUM CLEARANCES TO COMBUSTIBLES A Unit to sidewall. 4.5”... -
Page 24: Minimum Fireplace Dimensions
INSTALLATION CLEARANCES Clarity CL2714 SP Page 24 MINIMUM FIREPLACE DIMENSIONS The minimum fireplace dimensions the this insert are in the following diagrams and chart: COMBUSTIBLE FLOOR IN FRONT CAN BE LEVEL WITH HEARTH AND CL2714 LEVELING BOLTS MUST BE INSTALLED. Max. -
Page 25: Optional Blower
Clarity CL2714 SP OPTIONAL BLOWER Page 25 S.Z4946.SP BLOWER INSTALLATION 5. Feed the power cord wires through the case hole. 1. If attached, lift face frame and safety screen up and out, away from the appliance, and set it aside. 2. - Page 26 OPTIONAL BLOWER Clarity CL2714 SP Page 26 8. Remove the two screws holding the control panel 11. Attach star washer, nut, and knob to rheostat post. and dissconnect the switch wires from the valve.. 12. Connect the black “W” wire from the rheostat to the white “W”...
- Page 27 Clarity CL2714 SP OPTIONAL BLOWER Page 27 14. Slide the blower in on the left side, beside the leg, 16. Connect the black “B” wire from the blower to the around to the back of the case, keep wires from black “B”...
-
Page 28: Initial Setup
INSTALLATION Clarity CL2714 SP Page 28 INITIAL SETUP 1. There are six leveling bolts on the appliance as shown in (Fig.9). Level the appliance from side to side and front to back. Adjust the leveling bolts to desired vertical position so the appliance is level. -
Page 29: Vent Termination Location
Clarity CL2714 SP INSTALLATION Page 29 VENT TERMINATION LOCATION • In heavy snowfall areas make sure vent termination is located where it will not be blocked by snowfall or snow from snow removal equipment. • Locate vent termination away from plants, bushes, or any other object on or near the vent termination that will interfere or obstruct the air flow around it. -
Page 30: Vent Connector Removal And Installation
INSTALLATION Clarity CL2714 SP Page 30 VENT CONNECTOR REMOVAL AND INSTALLATION The vent connector slide plate is shipped attached to the insert, but may be removed and attached to flex vent for tight installations. NOTE: The vent connector slide plate gasket must not be damaged or removed. -
Page 31: Vent Restrictor
Clarity CL2714 SP INSTALLATION Page 31 VENT RESTRICTOR Due to the high draft produced by certain venting configurations the vent restrictor may be adjusted to maintain performance. If vent restriction is necessary it can be adjusted as follows: 1. Turn off the appliance and allow it to cool down completely. -
Page 32: Air Shutter Adjustment
INSTALLATION Clarity CL2714 SP Page 32 AIR SHUTTER ADJUSTMENT The air shutter allows the amount of air coming into the burner to be adjusted in order to accommodate different climates and venting arrangements. 1. Remove the safety screen trim (see SAFETY SCREEN TRIM REMOVAL). -
Page 33: Electrical Requirements
Clarity CL2714 SP INSTALLATION Page 33 ELECTRICAL REQUIREMENTS ELECTRICAL GROUNDING INSTRUCTIONS THIS APPLIANCE IS EQUIPPED WITH A GROUND SCREW FOR YOUR PROTECTION AGAINST SHOCK HAZARD. ENSURE PROPER GROUNDED WIRING IS SUPPLIED AND CONNECTED TO THIS UNIT. LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. -
Page 34: Venting Parts List
VENTING PARTS LIST Clarity CL2714 SP Page 34 M&G DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST DESCRIPTION PART OLD PART Aluminum Flex Length - 3” 3DFA-35 Flex Coupling - 3” 3DFA-FC Co-Axial to Co-linear Appliance Connector 46DVA-GCL Chimney Liner Termination Kit 46DVA-GK Co-Linear Kit w/ Flex 46DVA-CL33-25... - Page 35 Clarity CL2714 SP VENTING PARTS LIST Page 35 BDM PARTS LIST ORDER # DESCRIPTION PROFORM 35’ INSERT CO-LINEAR TERMINATION KITS: 94203370 3"X3"VCL PROFORM KIT 35'X 2 94203370B 3"X3"VCL PROFORM KIT 35'X 2 W/ BLACK CAP PROFORM INSERT CO-LINEAR INSULATED KITS: 942103360 3"X3"VCL PROFORM INSULATED KIT 30'X 2 942103360B...
- Page 36 VENTING PARTS LIST Clarity CL2714 SP Page 36 OLYMPIA PARTS LIST KITS PART DESCRIPTION VDV-CKVCCH33 3”x3” Co-Linear Kit that includes a High Wind Vertical Cap, 2 3”x35’ rolls of Aluminum Liner and 4 hose clamps VDV-CK33CC Square Style 3”x3” Stainless Steel Co-Linear Cap and 2 Hose clamps. The cap has 2 built-in Hose Clamps VDVB-CK33CC Square Style 3”x3”...
-
Page 37: Valve Removal & Installation
Clarity CL2714 SP VALVE REMOVAL & INSTALLATION Page 37 TO BE DONE BY QUALIFIED PERSONNEL ONLY 1. Turn off the gas valve, disconnect the gas and electricity to the appliance. 2. Remove safety screen trim. (see SAFETY SCREEN TRIM REMOVAL) 3. -
Page 38: Parts List
PARTS LIST Clarity CL2714 SP Page 38 ITEM PART DESCRIPTION NUMBER 4911 BAFFLE Z4910 FLOOR PLATE 640-4900 14” WIDE BURNER 610-0712 PILOT ASM ADJ NG/LPG PSE Z4914 SP VALVE ASM Z4917 CL2714 DOOR ASSEMBLY 4980 SECONDARY TRIM 645-1630 SAFETY SCREEN 16” X 30.5” S.Z4921 SAFETY SCREEN TRIM w/ SCREEN 145-0725... -
Page 39: Troubleshooting
Clarity CL2714 SP TROUBLESHOOTING Page 39 Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. TROUBLESHOOTING AND SERVICING OF GAS AND ELECTRICAL DEVICES OF THE APPLIANCE SHOULD ONLY BE CONDUCTED BY A QUALIFIED SERVICE TECHNICIAN PROBLEM POSSIBLE CAUSE ACTION... -
Page 40: Warranty
Blaze King and its respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts. - Page 41 If you are not satisfied with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
- Page 42 18. The paint on the brick liner may peel. It is not a flaw and is not covered under warranty, due to extreme conditions in the firebox. 19. Blaze King is free of liability for any damages caused by the fireplace or stove, as well as inconvenience expenses and materials. The Limited Warranty does not cover incidental or consequential damages.
- Page 43 Labor rates are set per component and as such total labor costs may not be covered. 26. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King will not be liable for travel costs for service work.
-
Page 44: Notes
NOTES Clarity CL2714 SP Page 44 180-CL2714.SP v1.00 July 30, 2020...
