- Page 1 User manual base•low•pro Stargarder Straße 2 30900 Wedemark Germany Phone: + 49-5130-37 10 05 Fax: + 49-5130-37 10 06 E-Mail: info@hazebase.com contact www.hazebase.com...
-
Page 2: Table Of Contents
6. Adjust screensaver ......................... 13 7. Show device information ....................... 14 8. Factory Reset .......................... 14 9. Scope of Delivery ........................15 10. Technical data ........................15 11. Accessories ........................... 16 12. Warranty conditions ......................17 13. Contact ..........................18 www.hazebase.com... -
Page 3: Introduction
• Spilled fluid or splashed fluid droplets can cause slip hazard. Mop up the fluid and dispose of it according to regulations. hazebase fog liquid is an enviromentally safe product and it can be recycled biologically. Artificially-made fog can be produced in many different ways. The method used here to produce fog, with a device which works according to the vaporizer principle, is the most harmless one. -
Page 4: Working With Co
• free from dusty or polluted air • free from vibrations • located on an non-flammable place or surface • Well-ventilated with fog-free air keeping the ambient operating temperature between 5°C and 45°C and the relative air humidity below 80% www.hazebase.com... -
Page 5: Devicelabeling
D) 5-pin-XLR DMX output (DMX512) B) Touchscreen operation unit E) 5-pin-XLR DMX input (DMX512) C) 3-pin-XLR analog output F) Art-Net RJ45 Ethernet rear view: G) PowerCon Power-Out J) 3-pin-XLR analog output H) PowerCon Power-In K) CO connection I) 5-pin-XLR DMX input (DMX512) www.hazebase.com... -
Page 6: First Steps
DMX start address „001“. 7. Now the base•low•pro is ready to start. Wait until the connected fogger is fully heated. This takes about 7min at Hazebase foggers. For more informa- tion, please refer to the manual of your fog machine. -
Page 7: Operating The Base•Low•Pro
4.3 Operation via DMX 4.2 manual mode After turning on the base•low•pro the hazebase logo appears on the display ( B ). The following figure shows the main menu of the base•low•pro. L) Display analog input: show the selected mode and P) Ethernet display: shows which protocol is selected current voltage. -
Page 8: Manual Mode
There are 6 presets available. Three fixed and three user-definable. The following table shows the pre-defined presets . Preset Values effect Fog: 35, Air: 20, CO ~150m² up to 10cm in 1 min. Fog: 45, Air: 30, CO ~150m² 15cm in 1 min. Fog: 50, Air: 30, CO ~150m² 20cm in 30sec. user-definable presets www.hazebase.com... -
Page 9: Operation Via Dmx
130 - 194 2kg/min CO output 195 - 255 3kg/min CO output 0 - 255 Fans will be passed on to the connected DMX fog machine. Connect the base•low•pro on your DMX network and control it with your DMX console faders. www.hazebase.com... -
Page 10: Operation Via Analog
With ANALOG SAVE the settings will be stored. With BACK you going back to the main menu without saving. If the latched mode on the base•low•pro is activated you must be disabled in the latched mode. Switching to another mode is not possible. www.hazebase.com... -
Page 11: Operation Via Ethernet
. With BACK you get to save the previous screen without settings . Make sure that in both cases the base•low•pro has a valid network address and subnet mask configured. You can check this check SETTINGS- > IP CONFIG and adjust if necessary. A detailed description follows on page 12 www.hazebase.com... -
Page 12: Setting Up The Ip Address
If ARTNET standard is used in your network select first of all STATIC and then press ARTNET. The IP address will formed from the immutable and MAC address of the device and an OEM code . The subnet mask is set to 255.0.0.0 . www.hazebase.com... -
Page 13: Adjust Brightness
SETTINGS - > NEXT - > SETTINGS 2 - > SCREENSAVER Here you can customize the duration of the screen saver. Press + or - to change the value. Click on SAVE to save your settings. With BACK you get back to the previous screen without saving. www.hazebase.com... -
Page 14: Show Device Information
SETTINGS - > NEXT - > SETTINGS 2 - > INFO Hier erhalten Sie Geräteinformationen des base•low•pro. With FIRMWAREUPDATE the update process can be released. Please inform yourself on the hazebase website for new firmware versions. With BACK you get back to the previous screen without saving. -
Page 15: Scope Of Delivery
English 9. Scope of Delivery You package from hazebase with your base•low•pro has the following items included: • base•low•pro • CO secruityhose 5m • distributionhose 10m • base•highpower fog machine • Amptown Flightcase For the best results of the base*low*pro we recommend to use the base*S. -
Page 16: Accessories
English 11. Accessories The following connection accessories are for CO bottles. Please contact hazebase for price information. Inline Filter Part No. 59069 material: steel wrench size: bottle connection Europe Part No. 59145 material: steel / brass / PTFE wrench size: T-fitting Part No. -
Page 17: Warranty Conditions
The right of guarantee service is also lost if fluids other than Original hazebase fluids have been used or if units are sent to us with full fluid bottles. -
Page 18: Contact
English 13. Contact hazebase Inhaberin Uta Raabe Stargarder Straße 2 30900 Wedemark Tel: +49 (0) 5130-371005 Fax: +49 (0) 5130-371006 info@hazebase.com www.hazebase.com www.hazebase.com...
