INSTALLATION GUIDE
Switch System
Counter Table
Size: 1600mm
05
Position as presented, and proceed to screw to ensure each corner of the frame.
If this bolt does not drop into the joint
use the Allen key to screw it all the way
in so that it creates its own thread.
This will ensure a nice, tight joint.
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Note: It is important to fully tighten all bolts and
screws before attaching the top(s) so that the frame is
su ciently rigid. Failure to do this may a ect stability
once the tops are attached.
06
Directly screw into table tops, using L-Bracket
screws through each L-Bracket.
Page 4 of 4
