Jason.L CUBO Assembly Instruction

REV : 00 DATE : 1.10.2014
MODEL :
CUBO
Assembly
Instruction
DRWG NO :
PG-AI-11
TITLE :

LOWER UNIT

LEGEND :

A.10(Dia) X 14(deep)
B.8(Dia) X 14(deep)
D.8(Dia) X 30(deep)
E.15(Dia) X 14(deep)
F.5(Dia) X 14(deep)
G.5(Dia) X Marking
H.5(Dia) X Through
J.35(Dia) X 13(deep)
S.10(Dia) X Through
T.Ø8 D,nut X 14(deep)
Edging 0.35mm
Edging 2mm

SCALE :

NIL
+ -

TOLERANCE :

0.5MM

DRWN BY :

LKL
1.10.2014
DATE :

CHECKED BY :

DATE :

REFERENCES :

DE TAIL A
A
C
CUB-CRTA-CAP
CUB-CRTA-CNT
S-PHS#8 x3/4
MF-RCF-VB4 0
DE TAIL C
