- Page 1 特种计算机 Industrial Computer 产品说明书 User Manual MEC-4032 微型低功耗无风扇嵌入式整机 Low Power Fanless Micro Embedded PC Version: C02...
- Page 2 Please pay attention to the following instructions: Warning EVOC product can only be used according to the descriptions within the manual, including the contents and the relevant technical documents. If the products or components from other companies are required, please get the recommendation and grant from EVOC first.
- Page 3 Trademarks EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other product names mentioned herein are used for identification purposes only and may be trademark and/or registered trademarks of their respective companies.
- Page 4 About this manual Scope of the Manual The manual is appropriate for EVOC MEC-4032. Convention The term “the PC” or “the Product” within the manual usually stands for EVOC MEC-4032. Instructions Safety instructions To avoid property losses or individual injury, please pay attention to the safety instructions within the manual.
-
Page 5: Table Of Contents
C o n t e n t s 1. Product Introduction ....................1 1.1 Overview......................1 1.2 Specifications....................1 2. Application Scheme ....................4 2.1 Transportation ....................4 2.2 Storage ......................4 2.3 Opening the Box and Initial Examination............5 2.4 Mounting Mode ....................5 3. Device Connection....................6 3.1 Notices before Connection................6 3.2 Product Grounding..................6 3.3 Connecting the Device to Power..............7... - Page 6 5.3.2 Removing the Motherboard ...............16 5.4 Installation and Removal of Hard Drive ............16 5.5 Installation and Removal of Power Supply...........17 5.5.1 Installing the Power ................17 5.5.2 Removing the Power................17 5.6 Installing the Mounting Bracket..............18 6. Installing the Drivers ....................19 7. Appendix.........................20 7.1 Troubleshooting and Solutions..............20...
-
Page 7: Product Introduction
Product Introduction 1. Product Introduction 1.1 Overview MEC-4032 is a low power fanless micro embedded PC. The product contains chipset, and supports Windows XP, Intel® Atom™ D2550 + NM10 Windows 7, Linux operating systems. In addition, a pluggable installation method makes adding or removing HDD quicker and more convenient. - Page 8 Storage temperature: -30℃～70℃ 5%～95% (Non-condensing) Humidity Limits of radio disturbance are compliant with GB9254-2008, class A; Limits of immunity are compliant with the threshold of GB/T 17626.x MTBF≥100000h Reliability MTTR≤0.5h MEC-4032 - 2 -...
- Page 9 12-24VDC Input /Maximum5A; Power consumption of the PC: 13W (standby); Power consumption of the PC: 20W (operating 3D Power 100%) Note: The maximum support of the input voltage 9-32VDC, over this range, the machine will not boot. MEC-4032 - 3 -...
-
Page 10: Application Scheme
Under this circumstance, please make sure no water drop (condensation) is formed on the surface or interior of the device. If condensation is formed on the device, please wait for over twelve hours before connecting the device. MEC-4032 - 4 -... -
Page 11: Opening The Box And Initial Examination
● Please check whether the delivery contains the intact device and all of the independently ordered accessories. Please contact the customer service when any unconformity or transportation damages occur. 2.4 Mounting Mode □19″ Rack Mount □Desktop □Embedded Panel ■Wall Mount □VESA Standard Arm □Portable □Others___________ MEC-4032 - 5 -... -
Page 12: Device Connection
PC or the central grounding busbar on the device. The minimum cross section area of the cable shall be no less than 5mm , and the maximum ground resistance shall be no more than 0.1Ω. MEC-4032 - 6 -... -
Page 13: Connecting The Device To Power
PC to boot up the PC, and the power indicator will light up green. Danger Disconnect the power source and data cable during a lightning storm. Attention The PC is completely isolated from the power supply only by disconnecting the power connector. MEC-4032 - 7 -... -
Page 14: Instructions
Instructions 4. Instructions 4.1 Outer Appearance 4.2 Product Drawing and Installation Dimensions Unit: mm MEC-4032 - 8 -... -
Page 15: External Structure
⑦ Reset button ⑧ HDD indicator ⑨ ⑩ Power indicator USB5, USB6 Power on/off button Rear View Item Description COM1 LAN1 LAN2 LINE OUT Ground screw Power connector COM2 HDMI COM3 COM4 USB1/2 COM5 USB3/4 COM6 MEC-4032 - 9 -... -
Page 16: Operation Control
Meaning Description The PC is shut down or POWER Displaying PC status Green PC is operating Displaying hard drive No access Data being transmitted status Yellow 4.6 Jumper Setting COM2～COM6 support RS-232/RS-422/RS-485 mode selection，mode selection by MEC-4032 - 10 -... - Page 17 3 ON 3 OFF 3 OFF 4 OFF 4 ON 4 ON 1 NC 1 ON 1 OFF 2 NC 2 OFF 2 ON SW16 3 OFF 3 ON 3 ON 4 OFF 4 ON 4 ON MEC-4032 - 11 -...
- Page 18 1 OFF 1 OFF 2 OFF 2 ON 2 ON SW18、SW19 3 ON 3 OFF 3 OFF 4 OFF 4 ON 4 ON SW11 1 NC 1 ON 1 OFF 2 NC 2 OFF 2 ON MEC-4032 - 12 -...
- Page 19 3 OFF 3 ON 3 ON 4 OFF 4 ON 4 ON 1 NC 1 NC 1 NC 2 NC 2 NC 2 NC 3 NC 3 NC 3 NC 4 OFF 4 ON 4 ON MEC-4032 - 13 -...
-
Page 20: Assembly And Maintenance
5. Assembly and Maintenance 5.1 Overall Assembly Drawing Item Description Item Description Item Description Top cover Power supply Heat sink Motherboard Chassis Indicator panel Front panel HDD door HDD module Bottom cover Support bracket IO plate Rear panel MEC-4032 - 14 -... -
Page 21: Opening The Cover
5.3.1 Installing the Motherboard 1. Place the motherboard onto the bolts of the chassis by the direction of the arrow in the above picture, and tighten the screws; 2. Install the front panel, and tighten the screws. MEC-4032 - 15 -... -
Page 22: Removing The Motherboard
3. Remove the screws fixing the motherboard, and take out the motherboard along the direction of the arrow. 5.4 Installation and Removal of Hard Drive Open the hard drive door; Loosen the screws fixing the hard drive handle, and turn the handle to pull out MEC-4032 - 16 -... -
Page 23: Installation And Removal Of Power Supply
Place the power supply into the chassis along the direction of the arrow; Tighten the six screws fixing the power supply. 5.5.2 Removing the Power Danger Before removing the power module, please turn off the power and remove the power cord if any power has been connected. MEC-4032 - 17 -... -
Page 24: Installing The Mounting Bracket
Loosen the six screws fixing the power module. Pull the power module out along the direction of the arrow. 5.6 Installing the Mounting Bracket Align the mounting bracket with the screw holes on the bottom cover of the chassis; Tighten the screws. MEC-4032 - 18 -... -
Page 25: Installing The Drivers
Installing the Drivers 6. Installing the Drivers Please install the drivers of this product according to the enclosed CD; the installation steps are not introduced here. MEC-4032 - 19 -... -
Page 26: Appendix
2. Please check whether the display cable correctly Power cable or display connected with the display and cable is not connected the system unit. 3. Contact Technique Support if the screen remains black after implementing above measures. MEC-4032 - 20 -... - Page 27 The HDD power cable or disk (the hard disk shall be can be found when data cable is not connected installed with operating system powering on well. bootable) well connected. MEC-4032 - 21 -...
- Page 28 IO Poor contact of the slot. card, unstable fixing or improper card can be used dust-proof measures; please when used again. remove and install the card for a few times or use another slot. MEC-4032 - 22 -...
